A-WBP-O001DG-08TB01

Headers, Male Pins Overview

The A-WBP-O001DG-08TB01 is a rectangular power connector header manufactured by Assmann WSW Components. It features an 8-position configuration with a 3.00mm (0.118 inch) pitch. The component utilizes a surface mount termination style for PCB integration. Constructed with thermoplastic housing and brass contacts, it supports standard electrical interconnection requirements within electronic assemblies.

Headers, Male Pins Feature Summary

• Surface mount termination design for automated PCB assembly
• 8-position layout with 3.00mm pitch spacing
• Thermoplastic housing material construction

Headers, Male Pins Applications

• Electronic board-level interconnections
• Power distribution modules
• Industrial control system interfaces

Headers, Male Pins Procurement Notes

Verify the specific suffix TB01 against official manufacturer documentation to confirm surface mount compatibility and pin configuration. Ensure the ordering part number matches the exact mechanical dimensions required for the target printed circuit board footprint. Cross-reference with the latest datasheet to validate contact plating and material specifications before final procurement.

Headers, Male Pins Selection Notes

Select this component when a low-profile surface mount header is required for 8-wire connections. The 3.00mm pitch accommodates standard wire gauges for power applications. Consider thermal management and soldering profile compatibility during the design phase to ensure reliable joint formation on the target substrate.

Headers, Male Pins Part Context

This part belongs to the A-WBP series of rectangular power connectors from Assmann WSW Components. The series provides standardized solutions for board-to-board or cable-to-board connections. The specific model integrates robust mechanical stability with electrical reliability for industrial and commercial electronics.

Headers, Male Pins Replacement Considerations

Compatible substitutes include the A-WBP-O001DG-08SR01 variant, which shares the same 8-position count and 3.00mm pitch but utilizes a different termination style. Verify mechanical fit and electrical ratings before substitution.
