B43634B9157M000

B43634B9157M000 is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists EPCOS - TDK Electronics. Its product description is CAP ALUM 150UF 20% 400V SNAP TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for B43634B9157M000

• Description：CAP ALUM 150UF 20% 400V SNAP TH
• Series：B43634
• Mfr：EPCOS - TDK Electronics
• Package：Bulk
• Capacitance：150 µF
• Tolerance：±20%
• Voltage - Rated：400 V
• ESR (Equivalent Series Resistance)：720mOhm @ 100Hz
• Lifetime @ Temp.：8000 Hrs @ 85°C
• Operating Temperature：-25°C ~ 85°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：1.13 A @ 100 Hz
• Ripple Current @ High Frequency：-
• Lead Spacing：0.394" (10.00mm)
• Size / Dimension：0.984" Dia (25.00mm)
• Height - Seated (Max)：1.063" (27.00mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can - Snap-In
• Impedance：1.1 Ohms

Aluminum Electrolytic Capacitors datasheet and documents for B43634B9157M000
