BC857AW,135

$0.02

Description：TRANS PNP 45V 0.1A SOT-323
Series：-

SKU:ea3f727908e8 Category: Single Bipolar Transistors Brand: Nexperia USA Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：TRANS PNP 45V 0.1A SOT-323
Series：-
Mfr：Nexperia USA Inc.
Package：Bulk
Transistor Type：PNP
Current - Collector (Ic) (Max)：100 mA
Voltage - Collector Emitter Breakdown (Max)：45 V
Vce Saturation (Max) @ Ib, Ic：600mV @ 5mA, 100mA
Current - Collector Cutoff (Max)：15nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce：125 @ 2mA, 5V
Power - Max：200 mW
Frequency - Transition：100MHz
Operating Temperature：150°C (TJ)
Mounting Type：Surface Mount
Package / Case：SC-70, SOT-323
Supplier Device Package：SOT-323
Grade：Automotive
Qualification：AEC-Q101

Download product information

BC857AW,135

Overview

The BC857AW,135 is a PNP general-purpose transistor manufactured by Nexperia USA Inc. It operates with a maximum collector current of 100 mA and a collector-emitter breakdown voltage of 45 V. The device features a transition frequency of 100 MHz and a power dissipation rating of 200 mW. It is housed in an SOT-323 (SC-70) surface-mount package. Key electrical characteristics include a DC current gain (hFE) minimum of 125 at 2 mA and 5 V, and a collector-emitter saturation voltage of 600 mV at 5 mA base and 100 mA collector currents.

Feature Summary

PNP general-purpose transistor designed for small signal applications
Ultra-small leadless SMD plastic package for board space efficiency
High thermal stability with junction temperature up to 150°C

Applications

General-purpose small signal DC switching
Low and medium frequency AC amplification
Mobile device circuitry

Procurement Notes

Verify the specific suffix '135' against official Nexperia documentation to confirm reel packaging specifications. Ensure compatibility with RoHS3 directives and check for any recent Product Change Notifications regarding assembly sites or material composition updates prior to finalizing procurement orders.

Selection Notes

Select this component for designs requiring a compact PNP switch with moderate current handling capabilities. The SOT-323 package offers a footprint comparable to larger packages while maintaining similar power dissipation. Verify that the 45 V voltage rating meets the circuit's peak reverse voltage requirements and that the 100 mA limit accommodates the load current.

Part Context

This part belongs to the BC857 series of PNP transistors from Nexperia. It serves as the complement to the BC847AW NPN transistor. The series includes variants such as BC856W and BC858W, offering different gain ranges within the same SOT-323 package family for flexible design integration.
