BCP 69US E6327

Overview

The BCP 69US E6327 is a PNP silicon power bipolar junction transistor manufactured by Infineon Technologies. It features a single configuration housed in a SOT-223 surface-mount package. The device supports a maximum collector current of 1 A and a collector-emitter voltage rating of 20 V. Key electrical parameters include a minimum DC current gain (hFE) of 85, a transition frequency (fT) of 100 MHz, and a power dissipation capability of 1 W. The component operates within a temperature range from -55 °C to +150 °C.

Feature Summary

• PNP silicon construction for power switching applications
• Integrated thermal protection characteristics inherent to the SOT-223 package design
• High current handling capability suitable for amplifier stages

Applications

• General-purpose amplifier circuits
• Power switching modules
• Audio output stages

Procurement Notes

Verify the specific suffix 'US' against official Infineon documentation to confirm exact binning or tape-and-reel specifications. Confirm RoHS compliance status through the manufacturer's datasheet. Ensure the ordering part number matches the required packaging format for your assembly line.

Selection Notes

Select this component when a PNP transistor with 1 A continuous current and 20 V breakdown voltage is required. The SOT-223 package offers a balance between power handling and board space. Verify that the 100 MHz transition frequency meets the signal bandwidth requirements of the target circuit design.

Part Context

This component belongs to the BCP 69 series of power transistors. The series is designed for general-purpose amplification and switching tasks. Infineon utilizes standard silicon planar technology for these devices to ensure reliability in automotive and industrial environments.

Replacement Considerations

Consult official cross-reference lists for verified substitutes. Generic replacements must match the PNP polarity, 1 A current rating, 20 V voltage rating, and SOT-223 footprint.
