BLC6G27LS-100,118

Overview

The BLC6G27LS-100,118 is an RF LDMOS transistor manufactured by Ampleon. It operates within the 2.3 GHz to 2.7 GHz frequency range and delivers a rated output power of 100 W. The device features a dual N-channel configuration with a drain-source breakdown voltage (Vds) of 65 V. It utilizes SOT-895A packaging for surface mount applications. Key electrical characteristics include a typical gain of 14 dB and a maximum operating temperature of +225°C. This component is designed for high-efficiency radio frequency power amplification in broadband infrastructure environments.

Feature Summary

• Dual N-channel LDMOS architecture for balanced power handling
• Optimized performance in the 2.3–2.7 GHz cellular band
• High thermal stability supporting extreme junction temperatures

Applications

• 4G LTE base station power amplifiers
• Broadband RF signal generation
• Wireless communication infrastructure

Procurement Notes

Verify the specific suffix designation against official Ampleon documentation to confirm exact electrical tolerances and package variant. Ensure compatibility with existing PCB footprints for the SOT-895A form factor. Confirm that the intended application environment respects the specified maximum operating temperature limits. Cross-reference the part number with current manufacturer availability status prior to integration planning.

Selection Notes

Select this component when designing for the 2.3–2.7 GHz spectrum requiring 100 W output power. The dual-channel structure supports push-pull amplifier topologies common in cellular infrastructure. Evaluate thermal management requirements given the high power density and maximum junction temperature rating. Ensure biasing circuits align with the specific gate-source voltage thresholds defined in the official datasheet.

Part Context

This part belongs to Ampleon’s BLC series of RF power transistors, which are engineered for telecommunications infrastructure. The series leverages advanced LDMOS technology to provide reliable performance in demanding RF environments. These components are integral to modern wireless network hardware, supporting the transition to higher bandwidth standards.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Consult official Ampleon cross-reference guides for validated alternatives.
