CSD87352Q5D

$1.45

Description：MOSFET 2N-CH 30V 25A 8LSON
Series：NexFET™

SKU:0f3acc6f0350 Category: FET, MOSFET Arrays Brand: Texas Instruments

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：MOSFET 2N-CH 30V 25A 8LSON
Series：NexFET™
Mfr：Texas Instruments
Package：Tape & Reel (TR),Cut Tape (CT)
Technology：MOSFET (Metal Oxide)
Configuration：2 N-Channel (Dual)
FET Feature：Logic Level Gate
Drain to Source Voltage (Vdss)：30V
Current - Continuous Drain (Id) @ 25°C：25A
Rds On (Max) @ Id, Vgs：-
Vgs(th) (Max) @ Id：1.15V @ 250µA
Gate Charge (Qg) (Max) @ Vgs：12.5nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds：1800pF @ 15V
Power - Max：8.5W
Operating Temperature：-55°C ~ 150°C (TJ)
Mounting Type：Surface Mount
Package / Case：8-PowerLDFN
Supplier Device Package：8-LSON (5x6)
Grade：-
Qualification：-

Download product information

CSD87352Q5D

Overview

The CSD87352Q5D is a synchronous buck NexFET Power Block manufactured by Texas Instruments. It integrates two N-channel MOSFETs in an asymmetric configuration within an 8-LSON (5x6) package. The device features a drain-source voltage of 30V and a maximum power dissipation of 12W. Key electrical parameters include a gate charge of 13.7nC at 4.5V, an input capacitance of 1860pF at 15V, and a threshold voltage of 1.9V at 250µA. It operates within a temperature range of -55°C to 150°C TJ.

Feature Summary

Integrates dual N-channel MOSFETs in an asymmetric arrangement for synchronous buck applications
Utilizes NexFET technology to optimize switching performance and efficiency
Provides surface-mount installation in a compact 8-LSON package

Applications

Synchronous buck converter designs
Point-of-load power regulation
General-purpose DC-DC conversion stages

Procurement Notes

Verify the specific manufacturer datasheet revision and ordering information directly from Texas Instruments or authorized distributors. Confirm that the component meets RoHS3 compliance requirements and check for any specific handling instructions related to its moisture sensitivity level before procurement.

Selection Notes

Select this component for low-voltage, high-current synchronous rectification needs where space is constrained. Ensure the application voltage does not exceed the 30V rating and consider the thermal management capabilities required for the 12W power dissipation limit in the specified package.

Part Context

This part belongs to the NexFET Power Block family from Texas Instruments, designed specifically for synchronous buck converters. It combines power switches and drivers into a single package to reduce board space and improve system reliability compared to discrete solutions.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing circuit designs if considering alternative components from other manufacturers.
