DCA240EB160

Overview

The DCA240EB160 is a silicon diode module manufactured by SanRex Corporation, designed for general-purpose rectifier applications. It features a reverse voltage rating of 1600 V and an average forward current capacity of 240 A. The device utilizes a series connection configuration with two diode chips integrated into a single chassis-mount package. Key electrical parameters include a maximum forward voltage of 1.35 V at 750 A and a maximum operating temperature of 150 C. The component measures 94 mm in length, 33.9 mm in width, and 30 mm in height, weighing approximately 240 g.

Feature Summary

• Integrates two diode chips connected in series within a robust chassis-mount module structure.
• Engineered for high-current rectification with a 1600 V reverse voltage blocking capability.
• Utilizes silicon technology to support continuous operation up to 150 C junction temperature.

Applications

• Industrial power supply rectification circuits
• DC motor drive systems
• General-purpose high-voltage rectifier modules

Procurement Notes

Verify the manufacturer part number against official SanRex documentation to ensure authenticity. Confirm that the specific ordering suffix matches the required electrical characteristics and mounting style. Check RoHS compliance status as indicated in the datasheet. Ensure the procurement channel provides valid traceability documents. Cross-reference the lead time and production cycle with the supplier's current availability data before finalizing orders.

Selection Notes

Select this module when a single-chip solution is required for series-connected rectification in high-power applications. The chassis-mount design facilitates direct thermal coupling to heatsinks for efficient heat dissipation. Consider the 1.35 V forward voltage drop at high currents for thermal management calculations. Ensure the application voltage does not exceed the 1600 V reverse rating. Verify mechanical dimensions fit the intended enclosure or panel space constraints.

Part Context

This component belongs to the broader category of discrete semiconductor diode modules produced by SanRex Corporation. It serves as a specialized power electronic device distinct from standard discrete diodes or integrated circuits. The module format allows for higher current handling compared to individual components while maintaining compact packaging suitable for industrial equipment.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Users must consult official SanRex documentation or authorized distributors for verified cross-references. Do not assume functional equivalence with other models without verifying electrical parameters and pinout configurations.
