DDB6U50N22W1RPB11BPSA1

$34.46

Description：EASY BRIDGE MODULE
Series：-

SKU:b3515ba82769 Category: IGBT Modules Brand: Infineon Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：EASY BRIDGE MODULE
Series：-
Mfr：Infineon Technologies
Package：Tray
IGBT Type：-
Configuration：-
Vce(on) (Max) @ Vge, Ic：-
Input：-
NTC Thermistor：-
Operating Temperature：-
Mounting Type：-
Package / Case：-
Supplier Device Package：-
Voltage - Collector Emitter Breakdown (Max)：-
Current - Collector (Ic) (Max)：-
Power - Max：-
Current - Collector Cutoff (Max)：-
Input Capacitance (Cies) @ Vce：-

Download product information

DDB6U50N22W1RPB11BPSA1

Overview

The DDB6U50N22W1RP_B11 is an EasyBRIDGE module featuring a chopper configuration with PressFIT contacts and pre-applied thermal interface material. It integrates Trench IGBT 4 switches rated at VCES = 1700 V, ICN = 50 A, and ICRM = 100 A, alongside 2200 V rectifier diodes. The module supports a maximum junction temperature of 150°C and provides 4 kV AC insulation for one minute. Key electrical parameters include a collector-emitter saturation voltage of 2.40 V (typical) at 50 A and 25°C, and a forward voltage of 1.22 V (typical) for the rectifier diode at 50 A.
