Product Detailed Parameters
- Description：IGBT MOD 1200V 25A 20MW
- Series：EasyPACK™
- Mfr：Infineon Technologies
- Package：Tray
- IGBT Type：-
- Configuration：Three Phase Inverter
- Vce(on) (Max) @ Vge, Ic：2.65V @ 15V, 25A
- Input：Standard
- NTC Thermistor：Yes
- Operating Temperature：-40°C ~ 150°C (TJ)
- Mounting Type：Chassis Mount
- Package / Case：Module
- Supplier Device Package：Module
- Voltage - Collector Emitter Breakdown (Max)：1200 V
- Current - Collector (Ic) (Max)：25 A
- Power - Max：-
- Current - Collector Cutoff (Max)：1 mA
- Input Capacitance (Cies) @ Vce：2 nF @ 25 V
Download product information
Overview
The DF75R12W1H4FB11BOMA2 is a three-phase inverter IGBT module manufactured by Infineon Technologies. It features a 1200 V collector-emitter voltage rating and a 25 A continuous collector current capability. The device utilizes chassis mount packaging for robust mechanical integration. Key electrical parameters include a maximum power dissipation of 20 mW, as specified in component documentation. The module operates within a temperature range of -40°C to +150°C. This silicon-based component is designed for high-power applications requiring reliable switching performance.
Feature Summary
- Three-phase inverter configuration for efficient power conversion
- Chassis mount design for secure mechanical installation
- Integrated thermal management capabilities
Applications
- Industrial motor drives
- Uninterruptible power supplies (UPS)
- Induction heating systems
Procurement Notes
Verify the specific suffix BOMA2 against official Infineon documentation to confirm package type and terminal configuration. Ensure compatibility with existing cooling solutions due to chassis mount requirements. Cross-reference part numbers with authorized distributors to avoid counterfeit components. Confirm RoHS compliance status through current datasheets before finalizing procurement orders.
Selection Notes
Select this module for applications requiring a 1200 V rating and 25 A current capacity in a three-phase topology. Consider the chassis mount form factor when designing PCB or baseplate layouts. Evaluate thermal resistance characteristics against system heat sink capabilities. Compare against alternative Easy1B series modules if pinout flexibility is required.
Part Context
This component belongs to the Easy1B-2-1 family of IGBT modules from Infineon Technologies. The series is characterized by compact packaging suitable for various industrial power electronics applications. Modules in this family typically integrate TrenchStop™ technology for optimized switching losses and improved short-circuit withstand capability.
Replacement Considerations
Direct substitutes may include other Easy1B-2-1 variants with matching voltage and current ratings. Verify pin-to-pin compatibility and thermal interface dimensions before substitution. Consult Infineon's replacement guide for cross-referencing similar packages with different electrical specifications.
