F423MR12W1M1B11BOMA1

Description：LOW POWER EASY
Series：EasyPACK™

SKU:d481144da419 Category: IGBT Modules Brand: Infineon Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LOW POWER EASY
Series：EasyPACK™
Mfr：Infineon Technologies
Package：Tray
IGBT Type：Trench
Configuration：Full Bridge
Vce(on) (Max) @ Vge, Ic：-
Input：Standard
NTC Thermistor：Yes
Operating Temperature：-40°C ~ 150°C (TJ)
Mounting Type：Chassis Mount
Package / Case：Module
Supplier Device Package：AG-EASY1BM-2
Voltage - Collector Emitter Breakdown (Max)：1200 V
Current - Collector (Ic) (Max)：50 A
Power - Max：-
Current - Collector Cutoff (Max)：-
Input Capacitance (Cies) @ Vce：3.68 nF @ 800 V

Download product information

F423MR12W1M1B11BOMA1

Overview

The F423MR12W1M1B11BOMA1 is a CoolSiC Module IGBT featuring Trench Full Bridge technology. It utilizes screw mount installation within an Easy1B-2 package. The device supports dual N-Channel configuration with a Vds of 1.2 kV and Id of 25 A. Rds(on) is 45 mOhms, with Vgs thresholds at 3.5 V. Operating temperatures range from -40 C to +150 C. Switching characteristics include 13 ns fall time and 7.2 ns rise time. Delay times are 38.5 ns (off) and 11.5 ns (on). Vf is 4.6 V.

Feature Summary

Trench Full Bridge architecture for enhanced switching performance
CoolSiC Module integration for high-temperature reliability
Dual N-Channel configuration in compact Easy1B-2 form factor

Applications

Industrial motor drives
Inverter systems
High-frequency power conversion

Procurement Notes

Verify component authenticity through official Infineon channels or authorized distributors. Confirm RoHS compliance status via current datasheets. Check end-of-life notifications as discontinuance may affect long-term supply. Validate package markings against official specifications to prevent counterfeit substitution during acquisition.

Selection Notes

Evaluate thermal management requirements against the +150 C maximum junction temperature limit. Ensure gate drive voltage aligns with the specified Vgs range for optimal switching efficiency. Consider the 45 mOhms on-resistance for conduction loss calculations in low-current applications. Verify mechanical mounting compatibility with the Easy1B-2 screw mount interface.

Part Context

This module belongs to Infineon's CoolSiC family, combining silicon carbide benefits with IGBT topology. It targets applications requiring robust switching capabilities in compact footprints. The Easy1B-2 packaging facilitates standardized thermal and electrical connections. It represents a specialized solution for mid-power industrial electronics demanding high reliability.
