FS1606-1800-AL

FS1606-1800-AL is listed in the DC DC Converters range at ChipApex. The manufacturer field lists TDK Corporation. Its product description is TDK MPOL POWER MODULE, 1.80V. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for FS1606-1800-AL

• Description：TDK MPOL POWER MODULE, 1.80V
• Series：µPOL™ micro-POL
• Mfr：TDK Corporation
• Package：Tape & Reel (TR),Cut Tape (CT)
• Type：Non-Isolated PoL Module
• Number of Outputs：1
• Voltage - Input (Min)：4.2V
• Voltage - Input (Max)：16V
• Voltage - Output 1：1.8V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：6A
• Power (Watts)：11 W
• Voltage - Isolation：-
• Applications：ITE (Commercial)
• Features：Adjustable Output, Heat Sink
• Operating Temperature：-40°C ~ 125°C (With Derating)
• Efficiency：-
• Mounting Type：Surface Mount
• Package / Case：17-SMD Module
• Size / Dimension：0.13" L x 0.13" W x 0.05" H (3.3mm x 3.3mm x 1.4mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for FS1606-1800-AL
