FST160100

$53.24

Description：DIODE MOD SCHOTTKY 100V TO-249AB
Series：-

SKU:824381f6fda0 Category: Diode Arrays Brand: GeneSiC Semiconductor

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

FST160100 is listed in the Diode Arrays range at ChipApex. The manufacturer field lists GeneSiC Semiconductor. Its product description is DIODE MOD SCHOTTKY 100V TO-249AB. Review the specifications below when checking this part for your BOM.

Diode Arrays specifications for FST160100

Description：DIODE MOD SCHOTTKY 100V TO-249AB
Series：-
Mfr：GeneSiC Semiconductor
Package：Bulk
Diode Configuration：1 Pair Common Cathode
Technology：Schottky
Voltage - DC Reverse (Vr) (Max)：100 V
Current - Average Rectified (Io) (per Diode)：160A (DC)
Voltage - Forward (Vf) (Max) @ If：880 mV @ 160 A
Speed：Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)：-
Current - Reverse Leakage @ Vr：1 mA @ 20 V
Operating Temperature - Junction：-55°C ~ 150°C
Mounting Type：Chassis Mount
Package / Case：TO-249AB
Supplier Device Package：TO-249AB
Grade：-
Qualification：-

Diode Arrays datasheet and documents for FST160100

FST160100

Diode Arrays Overview

The FST160100 is a silicon power Schottky diode module manufactured by GeneSiC Semiconductor. It features a TO-249AB package with an isolated plate design and is not ESD sensitive. The device supports a repetitive peak reverse voltage of 100 V, with RMS and DC blocking voltages of 71 V and 100 V respectively. It provides an average forward current of 160 A per package and a peak forward surge current of 1000 A per leg. The junction-to-case thermal resistance is 0.50 °C/W per leg, and the maximum instantaneous forward voltage is 0.84 V at Tj = 150 °C.

Diode Arrays Feature Summary

High surge capability for robust transient handling
Isolated to plate construction for electrical safety
Not ESD sensitive for simplified handling

Diode Arrays Applications

DC-DC converters
Free-wheeling rectification in motor drives
Power supply output rectification

Diode Arrays Procurement Notes

Verify the specific part number suffix against official datasheets to confirm voltage ratings and package variations. Ensure thermal management solutions align with the specified junction-to-case thermal resistance. Confirm operating temperature ranges meet system requirements before integration.

Diode Arrays Selection Notes

Select this component for applications requiring high current density and low forward voltage drop. Consider the TO-249AB package dimensions for mechanical fit. Evaluate thermal performance based on the 0.50 °C/W junction-to-case resistance under expected load conditions.

Diode Arrays Part Context

This module belongs to the FST160 series, which includes variants from 45 V to 100 V VRRM. All models share the same 160 A average forward current rating and TO-249AB package form factor, differing primarily in reverse voltage specifications.

Diode Arrays Replacement Considerations

Cross-reference with other 160 A Schottky modules in TO-249AB packages. Verify compatibility of pinout and thermal characteristics when substituting with equivalent parts from other manufacturers.
