Product Detailed Parameters
- Description：CIPOS MICRO
- Series：IM241, CIPOS™
- Mfr：Infineon Technologies
- Package：Tube
- IGBT Type：-
- Configuration：Three Phase Inverter
- Vce(on) (Max) @ Vge, Ic：1.58V @ 15V, 1A
- Input：Standard
- NTC Thermistor：Yes
- Operating Temperature：-40°C ~ 150°C (TJ)
- Mounting Type：Through Hole
- Package / Case：-
- Supplier Device Package：23-DIP
- Voltage - Collector Emitter Breakdown (Max)：600 V
- Current - Collector (Ic) (Max)：-
- Power - Max：13 W
- Current - Collector Cutoff (Max)：-
- Input Capacitance (Cies) @ Vce：-
Download product information
Overview
The IM241M6T2JAKMA1 is a CIPOS Micro intelligent power module featuring a 600 V reverse conducting IGBT and integrated gate drivers. It operates with a maximum DC link voltage of 400 V and a rated collector current of 4 A. The device utilizes a DIP 29x12 package and includes an internal NTC thermistor for thermal monitoring. Designed for low EMI applications, it offers optimized switching speeds and comprehensive protection features including overcurrent shutdown and fault reporting.
Feature Summary
- Integrated bootstrap functionality with isolated high-side floating supply
- Programmable fault clear timer and precise overcurrent protection via ITRIP pin
- Low-side emitter pins accessible for individual phase current monitoring
- Built-in input noise filter and shoot-through prevention circuitry
Applications
- High-efficiency appliance motor drives
- Fan and pump control systems
- Small home appliances
Procurement Notes
Verify the specific ordering suffix against official Infineon documentation to confirm package type and lead time requirements. Ensure the component matches the intended industrial qualification standards. Cross-reference the datasheet version to validate parameter accuracy before finalizing procurement orders.
Selection Notes
Select this variant for applications requiring low electromagnetic interference due to its slow speed switching configuration. Verify that the system design accommodates the specified thermal resistance values and isolation voltage ratings. Confirm compatibility with 3.3 V or 5.0 V logic controllers for proper interface operation.
Part Context
This component belongs to the CIPOS Micro IM241 product group, which integrates power and control components to optimize PCB size and system costs. The series provides both fast and slow speed versions to address different loss and EMI trade-offs in three-phase open emitter configurations.
Replacement Considerations
The IM241-M6T2B serves as the fast-speed alternative within the same package family. Verify functional equivalence regarding pinout and electrical characteristics before substitution.
