IPDQ60T022S7AXTMA1

$9.34

Description：AUTOMOTIVE_COOLMOS
Series：-
Mfr：Infineon Technologies
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:078c27c1af6d Category: Single FETs, MOSFETs Brand: Infineon Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

IPDQ60T022S7AXTMA1 is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Infineon Technologies. Its product description is AUTOMOTIVE_COOLMOS. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for IPDQ60T022S7AXTMA1

Description：AUTOMOTIVE_COOLMOS
Series：-
Mfr：Infineon Technologies
Package：Tape & Reel (TR),Cut Tape (CT)
FET Type：-
Technology：-
Drain to Source Voltage (Vdss)：-
Current - Continuous Drain (Id) @ 25°C：-
Drive Voltage (Max Rds On, Min Rds On)：-
Rds On (Max) @ Id, Vgs：-
Vgs(th) (Max) @ Id：-
Gate Charge (Qg) (Max) @ Vgs：-
Vgs (Max)：-
Input Capacitance (Ciss) (Max) @ Vds：-
FET Feature：-
Power Dissipation (Max)：-
Operating Temperature：-
Grade：-
Qualification：-
Mounting Type：-
Supplier Device Package：-
Package / Case：-

Single FETs, MOSFETs datasheet and documents for IPDQ60T022S7AXTMA1

IPDQ60T022S7AXTMA1

Single FETs, MOSFETs Overview

The IPDQ60T022S7A is a 600V CoolMOS S7TA N-channel superjunction MOSFET in PG-HDSOP-22 package. It features an embedded temperature sensor for junction monitoring. Key parameters include RDS(on) of 22 mΩ, Qg of 150 nC, and pulsed drain current of 371 A. The device supports up to 416 W power dissipation at 25°C case temperature.

Single FETs, MOSFETs Feature Summary

Integrated temperature sensor for accurate junction temperature sensing
Optimized for low-frequency switching applications with high pulse current capability
Seamless diagnostics implementation reducing external sensing elements

Single FETs, MOSFETs Applications

HV eFuse
Circuit breakers
On-board charger

Single FETs, MOSFETs Procurement Notes

Verify the specific suffix 'XTMA1' against the datasheet part number 'IPDQ60T022S7A'. Confirm that the source and sense source pins are not exchangeable to prevent malfunction. Ensure application notes regarding cosmic radiation effects are reviewed for designs with blocking voltages exceeding 400V.

Single FETs, MOSFETs Selection Notes

Select this component for static switching and high current applications requiring thermal protection. The integrated sensor simplifies system design by eliminating external sensing components. Verify compatibility with driver circuits due to the specific pinout configuration of the PG-HDSOP-22 package.

Single FETs, MOSFETs Part Context

This device belongs to the CoolMOS S7TA family, which extends the S7 series with an embedded temperature sensor. It is designed for automotive and industrial applications where robust thermal management and compact design are critical. The technology offers improved price-performance for low-frequency switching.
