Product Detailed Parameters
- Description：IGBT 600V 65A TO-262
- Series：-
- Mfr：International Rectifier
- Package：Bulk
- IGBT Type：-
- Voltage - Collector Emitter Breakdown (Max)：600 V
- Current - Collector (Ic) (Max)：65 A
- Current - Collector Pulsed (Icm)：72 A
- Vce(on) (Max) @ Vge, Ic：1.9V @ 15V, 24A
- Power - Max：250 W
- Switching Energy：115µJ (on), 600µJ (off)
- Input Type：Standard
- Gate Charge：75 nC
- Td (on/off) @ 25°C：41ns/104ns
- Test Condition：400V, 24A, 10Ohm, 15V
- Reverse Recovery Time (trr)：89 ns
- Operating Temperature：-55°C ~ 175°C (TJ)
- Mounting Type：Through Hole
- Package / Case：TO-262-3 Long Leads, I2PAK, TO-262AA
- Supplier Device Package：TO-262
- Grade：-
- Qualification：-
Download product information
Overview
The IRGSL4640DPBF is a 600V ultrafast Insulated Gate Bipolar Transistor (IGBT) manufactured by International Rectifier. It utilizes trench gate technology to minimize conduction and switching losses, making it suitable for high-frequency operation between 8kHz and 30kHz. The device features a short-circuit rating of 5 microseconds and includes an integrated soft-recovery diode with low reverse recovery charge. Key electrical parameters include a collector-emitter saturation voltage of 1.6V at 40A, a breakdown voltage of 600V, and a thermal resistance from junction to case of 0.60°C/W. It operates within a maximum junction temperature of 175°C.
Feature Summary
- Trench gate architecture reduces both conduction and switching energy losses.
- Integrated ultrafast soft-recovery diode minimizes reverse recovery charge.
- Positive temperature coefficient of Vce(on) facilitates safe parallel operation.
- Robust 5-microsecond short-circuit withstand capability.
Applications
- Uninterruptible Power Supplies (UPS)
- Solar Inverters
- Induction Heating Systems
- Industrial Motor Drives
- Welding Equipment
Procurement Notes
Verify the specific suffix against official datasheets to confirm compliance standards and pinout compatibility. Ensure the component matches the required current rating and package variant for your thermal design. Cross-reference manufacturer documentation to validate authenticity and avoid counterfeit parts during sourcing.
Selection Notes
Select this IGBT for applications requiring high efficiency in the 8kHz to 30kHz range. The integrated diode simplifies circuit design by eliminating external freewheeling components. Consider the 0.60°C/W thermal resistance for heatsink calculations. Ensure gate drive voltages align with standard IGBT requirements to optimize switching performance.
Part Context
This component belongs to International Rectifier's 600V channel ultrafast IGBT series. It shares architectural similarities with models like the IRGP4640D but may differ in specific packaging or environmental compliance markings. The series is designed to offer robust performance for power conversion systems requiring fast switching speeds.
Replacement Considerations
Direct substitutes include the IRGP4640D and IRGP4640-EPBF. Verify that replacement packages match the host board footprint. Confirm that thermal resistance and short-circuit ratings are equivalent to maintain system reliability. Check for any differences in diode characteristics if precise snubber design is critical.
