IXYK200N65B3

Overview

The IXYK200N65B3 is a high-power N-channel IGBT module from IXYS, designed for demanding industrial applications. It features a Trench Field-Stop technology that optimizes switching losses and conduction voltage drop. The module utilizes a copper baseplate for superior thermal conductivity and mechanical stability. Key electrical parameters include a collector-emitter voltage of 650V and a continuous collector current of 200A at 25°C case temperature. It incorporates an integrated anti-parallel diode with fast recovery characteristics. The device is housed in a robust insulated package suitable for high-current power conversion systems.

Feature Summary

• Trench Field-Stop IGBT technology for optimized efficiency
• Integrated fast recovery anti-parallel diode
• Copper baseplate for enhanced thermal management

Applications

• Industrial motor drives
• Uninterruptible power supplies (UPS)
• High-frequency inverters

Procurement Notes

Verify the specific suffix code on the component marking to ensure compatibility with your system requirements. Confirm thermal interface material specifications and mounting torque values against the official datasheet before installation. Check for any recent design changes or obsolescence notices from the manufacturer to ensure long-term supply availability.

Selection Notes

Select this module based on its 650V rating and 200A current capacity for medium-to-high power applications. Ensure the cooling solution can maintain the junction temperature within specified limits under peak load conditions. Consider the switching frequency requirements of the application to leverage the device's low loss characteristics effectively.

Part Context

This component belongs to IXYS' high-performance IGBT module series, targeting efficient power conversion. It represents a balance between high current handling and low switching losses, making it suitable for modern energy-efficient industrial equipment. The B3 designation typically indicates specific internal configuration and packaging details within the product line.

Replacement Considerations

Direct replacements must match the 650V/200A specification and pinout configuration. Verify thermal resistance and gate drive requirements when substituting with equivalent parts from other manufacturers. Consult official cross-reference lists for confirmed compatible alternatives.
