M50-4802245

Headers, Male Pins Overview

The Harwin M50-4802245 is a right-angle, surface-mount board-to-board header from the Archer M50 series. It features a dual-row configuration with 26 positions and a 1.27mm (0.050 inch) pitch. The connector utilizes gold-plated contacts for reliable signal transmission and includes four-wall shrouding to guide mating pins. Mechanical stability is enhanced by integrated push-pull retention mechanisms designed to withstand vibration. The component is RoHS compliant and suitable for high-density electronic assemblies requiring secure vertical interconnects.

Headers, Male Pins Feature Summary

• Four-wall shrouded design ensures precise pin alignment during mating
• Push-pull retention mechanism provides mechanical stability against vibration
• Right-angle termination facilitates compact circuit board layouts
• Gold-plated contacts ensure durable electrical performance

Headers, Male Pins Applications

• High-density electronic assemblies
• Vibration-prone industrial equipment
• Compact consumer electronics
• Automotive control modules

Headers, Male Pins Procurement Notes

Verify the specific quantity of positions and orientation against official datasheets before procurement. Confirm that the right-angle surface-mount package matches the target PCB footprint requirements. Ensure compatibility with the intended mating header within the Archer M50 ecosystem. Check for RoHS compliance documentation if required by project specifications.

Headers, Male Pins Selection Notes

Select this component when space constraints necessitate a right-angle connection between closely spaced boards. The push-pull feature is critical for applications subject to mechanical stress or vibration. Ensure the mating partner supports the 1.27mm pitch and compatible shrouding geometry. Consider the surface-mount profile height relative to adjacent components on the assembly.

Headers, Male Pins Part Context

This part belongs to the Harwin Archer M50 family, known for high-reliability interconnects. The series offers various configurations including through-hole and surface-mount options. The M50-4802245 specifically addresses needs for robust, vibration-resistant connections in dense layouts. It complements other headers and receptacles within the same architectural standard.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 1.27mm pitch, 26-position count, right-angle orientation, and shrouded design. Verify that alternative connectors support identical push-pull retention mechanisms. Cross-reference mounting dimensions and contact plating specifications to ensure functional equivalence without redesigning the PCB.

Headers, Male Pins FAQ

What type of retention mechanism does the M50-4802245 use?

It uses a push-pull retention mechanism to provide mechanical stability.

Is the connector shrouded?

Yes, it features four-wall shrouding for guided mating.
