Product Detailed Parameters
- Description：POWER MODULE DIODE M SERIES
- Series：M50
- Mfr：Sensata-Crydom
- Package：-
- Structure：Bridge, Single Phase - SCRs/Diodes (Layout 2)
- Number of SCRs, Diodes：2 SCRs, 2 Diodes
- Voltage - Off State：600 V
- Current - On State (It (AV)) (Max)：-
- Current - On State (It (RMS)) (Max)：50 A
- Current - Non Rep. Surge 50, 60Hz (Itsm)：1500A @ 60Hz
- Operating Temperature：-40°C ~ 125°C (TJ)
- Mounting Type：Chassis Mount
- Package / Case：Module
- Voltage - Gate Trigger (Vgt) (Max)：3 V
- Current - Gate Trigger (Igt) (Max)：150 mA
- Current - Hold (Ih) (Max)：-
- Grade：-
- Qualification：-
Download product information
Overview
The Sensata-Crydom M50100TB600 is a three-phase bridge rectifier diode module designed for high-power applications. It features a silicon construction with a peak reverse voltage of 600 V and an average forward current rating of 100 A. The module utilizes a screw mount installation style within the M50 package configuration. Key electrical parameters include a maximum forward voltage of 1.2 V and a surge current capacity of 1.5 kA. It operates reliably across a temperature range from -40°C to +125°C, ensuring stability in demanding industrial environments.
Feature Summary
- Three-phase bridge rectifier topology for efficient AC-to-DC conversion
- Robust mechanical design with screw mount terminals for secure panel integration
- High thermal performance supporting operation up to 125°C junction temperature
Applications
- Industrial motor drive systems
- Power supply units requiring three-phase rectification
- Welding equipment power stages
Procurement Notes
Verify component authenticity through authorized Sensata-Crydom distributors or certified partners. Confirm that the received unit matches the M50100TB600 part number and packaging details. Ensure storage conditions comply with manufacturer guidelines to prevent moisture absorption prior to soldering or mounting. Review the latest datasheet for any updates on compliance standards such as RoHS and REACH before final procurement approval.
Selection Notes
Select this module when a three-phase rectification solution is required with a 100 A current rating and 600 V blocking capability. The M50 package offers a compact footprint suitable for panel mounting in space-constrained enclosures. Consider the 1.2 V forward voltage drop for thermal management calculations. Ensure the application environment supports the specified operating temperature range of -40°C to +125°C for optimal reliability.
Part Context
The M50100TB600 belongs to the Crydom M50 Diode series, which provides standardized power modules for industrial electronics. This series is known for its rugged construction and consistent performance in high-current applications. The M50 family includes various configurations, but this specific model is dedicated to three-phase bridge rectification, distinguishing it from single-phase or dual-diode variants within the same product line.
Replacement Considerations
Direct substitutes may include other M50 series three-phase modules with identical electrical ratings. Verify pin compatibility and mounting hole dimensions when considering alternative manufacturers. Ensure the replacement part maintains the same 600 V and 100 A specifications to avoid derating issues in existing designs.
