MAL229967102E3

MAL229967102E3 is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Vishay Beyschlag/Draloric/BC Components. Its product description is CAP ALUM 1000UF 20% 450V SNAP TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for MAL229967102E3

• Description：CAP ALUM 1000UF 20% 450V SNAP TH
• Series：299 PHL-4TSI
• Mfr：Vishay Beyschlag/Draloric/BC Components
• Package：Bulk
• Capacitance：1000 µF
• Tolerance：±20%
• Voltage - Rated：450 V
• ESR (Equivalent Series Resistance)：110mOhm @ 100Hz
• Lifetime @ Temp.：5000 Hrs @ 105°C
• Operating Temperature：-40°C ~ 105°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：4.41 A @ 100 Hz
• Ripple Current @ High Frequency：6.615 A @ 10 kHz
• Lead Spacing：0.886" (22.50mm)
• Size / Dimension：1.575" Dia (40.00mm)
• Height - Seated (Max)：3.228" (82.00mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can - Snap-In - 4 Lead
• Impedance：110 mOhms
