MCTL150N06YHE3-TP

$4.53

Description：N-CHANNEL MOSFET,TOLL-8L
Series：-
Mfr：MCC (Micro Commercial Components)
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:303de277a7d5 Category: Single FETs, MOSFETs Brand: MCC (Micro Commercial Components)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MCTL150N06YHE3-TP is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists MCC (Micro Commercial Components). Its product description is N-CHANNEL MOSFET,TOLL-8L. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for MCTL150N06YHE3-TP

Description：N-CHANNEL MOSFET,TOLL-8L
Series：-
Mfr：MCC (Micro Commercial Components)
Package：Tape & Reel (TR),Cut Tape (CT)
FET Type：N-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：60 V
Current - Continuous Drain (Id) @ 25°C：150A (Tc)
Drive Voltage (Max Rds On, Min Rds On)：4.5V, 10V
Rds On (Max) @ Id, Vgs：2.4mOhm @ 30A, 10V
Vgs(th) (Max) @ Id：2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs：55.8 nC @ 10 V
Vgs (Max)：±20V
Input Capacitance (Ciss) (Max) @ Vds：3375 pF @ 25 V
FET Feature：-
Power Dissipation (Max)：158W (Tj)
Operating Temperature：-55°C ~ 175°C (TJ)
Grade：Automotive
Qualification：AEC-Q101
Mounting Type：Surface Mount
Supplier Device Package：TOLL-8L
Package / Case：8-PowerSFN

Single FETs, MOSFETs datasheet and documents for MCTL150N06YHE3-TP

MCTL150N06YHE3-TP

Single FETs, MOSFETs Overview

The MCTL150N06YHE3-TP is an N-channel MOSFET utilizing Split Gate Trench Technology, housed in a TOLL-8L package. It features a Drain-Source Voltage of 60V and a Continuous Drain Current of 150A at TC=25°C. The device exhibits a maximum RDS(on) of 2.4mΩ at VGS=10V/ID=30A. Thermal resistance is 0.95°C/W (Junction-to-Case). Operating junction temperature ranges from -55°C to +175°C. It is AEC-Q101 qualified, RoHS compliant, and Halogen-free.

Single FETs, MOSFETs Feature Summary

Split Gate Trench MOSFET technology for optimized performance
AEC-Q101 automotive qualification
Excellent heat dissipation via TOLL-8L package
Halogen-free "Green" device with UL 94 V-0 flammability rating

Single FETs, MOSFETs Applications

Automotive power switching applications
High-efficiency DC-DC converters
Motor control circuits

Single FETs, MOSFETs Procurement Notes

Verify the part number suffix "-TP" indicates Tape & Reel packaging containing 2000 pieces per reel. Confirm the "HE3" designation aligns with the manufacturer's specific product line requirements. Ensure sourcing is through authorized Micro Commercial Components distributors to guarantee traceability and compliance with quality standards.

Single FETs, MOSFETs Selection Notes

Select this component for designs requiring high current handling in a compact footprint. The low thermal resistance supports efficient heat management. Verify that the 60V breakdown voltage meets circuit requirements. Consider the TOLL-8L package dimensions for PCB layout constraints.

Single FETs, MOSFETs Part Context

Manufactured by Micro Commercial Components (MCC), this device belongs to their automotive-grade MOSFET portfolio. The TOLL-8L package provides superior thermal performance compared to standard surface-mount options. The product is designed to meet stringent automotive reliability standards.

Single FETs, MOSFETs Replacement Considerations

Cross-reference with other MCC N-channel MOSFETs in the TOLL-8L package. Verify pinout compatibility and electrical parameters such as RDS(on) and V(BR)DSS before substitution.
