MGW302412-R

MGW302412-R is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Cosel USA, Inc.. Its product description is DC DC CONVERTER +/-12V 24V 30W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for MGW302412-R

• Description：DC DC CONVERTER +/-12V 24V 30W
• Series：MGW (30W)
• Mfr：Cosel USA, Inc.
• Package：Box
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：18V
• Voltage - Input (Max)：36V
• Voltage - Output 1：12V or 24V
• Voltage - Output 2：-12V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：1.25A, 1.25A
• Power (Watts)：30 W
• Voltage - Isolation：1 kV
• Applications：ITE (Commercial)
• Features：Bridgeable
• Operating Temperature：-40°C ~ 85°C (With Derating)
• Efficiency：91%
• Mounting Type：Through Hole
• Package / Case：6-DIP Module
• Size / Dimension：2.00" L x 1.00" W x 0.39" H (50.8mm x 25.4mm x 9.9mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-

DC DC Converters datasheet and documents for MGW302412-R
