MIEB101H1200EH

Overview

The MIEB101H1200EH is an IGBT module manufactured by IXYS, designed for high-power switching applications. It features a half-bridge configuration with integrated anti-parallel diodes. The device supports a maximum collector-emitter voltage of 1200 V and offers continuous collector current ratings suitable for industrial power conversion. Constructed using silicon technology, it utilizes screw mount installation within a robust package to ensure reliable thermal management and mechanical stability under demanding operating conditions.

Feature Summary

• Half-bridge topology integrating IGBT switches with complementary diodes
• High-voltage capability rated at 1200 V for robust operation
• Screw mount design ensuring secure mechanical attachment

Applications

• Industrial motor drives
• Power inversion systems
• Uninterruptible power supplies

Procurement Notes

Verify component authenticity through authorized IXYS distributors or certified suppliers. Confirm the specific manufacturing date code and lot number against internal quality requirements. Ensure proper handling procedures are followed due to the sensitive nature of semiconductor components. Request original manufacturer documentation to validate specifications before integration into final assemblies.

Selection Notes

Select this module when a compact half-bridge solution is required for 1200 V DC bus applications. Evaluate thermal resistance parameters against the system's cooling capacity to maintain junction temperatures within safe limits. Consider the gate drive requirements compatible with the specified IGBT characteristics. Ensure the physical dimensions of the E3-pack style fit the available PCB or chassis space constraints.

Part Context

This component belongs to the IXYS IGBT module family, which provides solutions for efficient power conversion. The series is engineered for reliability in environments requiring stable performance under high electrical stress. IXYS designs these modules to meet stringent industry standards for power electronics, supporting various global regulatory compliance requirements.

Replacement Considerations

Direct substitutes must match the 1200 V rating, half-bridge configuration, and E3-pack footprint. Verify that alternative parts offer comparable saturation voltage and thermal resistance values. Cross-reference pinouts to ensure compatibility with existing gate drive circuits without modification.
