MW7IC2425NBR1

Description：RF MOSFET LDMOS 28V TO272-16
Series：-

SKU:0f51a1dbc81f Category: RF FETs, MOSFETs Brand: NXP USA Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF MOSFET LDMOS 28V TO272-16
Series：-
Mfr：NXP USA Inc.
Package：Tape & Reel (TR)
Technology：LDMOS
Frequency：2.45GHz
Gain：27.7dB
Voltage - Test：28 V
Current Rating (Amps)：-
Noise Figure：-
Current - Test：55 mA
Power - Output：25W
Voltage - Rated：65 V
Grade：-
Qualification：-
Mounting Type：Chassis Mount
Package / Case：TO-272-16 Variant, Flat Leads
Supplier Device Package：TO-272 WB-16
Configuration：-

Download product information

MW7IC2425NBR1

Overview

The MW7IC2425NBR1 is a lateral N-channel RF power MOSFET designed for CW large-signal output and driver applications at 2450 MHz. It operates with a drain-source voltage of 28 Vdc and delivers 25 Watts of continuous wave output power. The device features integrated quiescent current temperature compensation with an enable/disable function, ensuring excellent thermal stability. It includes internal matching on both input and output sides and provides integrated ESD protection.

Feature Summary

Integrated quiescent current temperature compensation with enable/disable functionality
Internal input and output impedance matching
Integrated electrostatic discharge (ESD) protection
Excellent thermal stability with high junction temperature capability

Applications

Industrial, medical, and scientific (IMS) applications
CW large-signal output stages
RF driver applications

Procurement Notes

Verify the specific ordering suffix to confirm the package type, as the MW7IC2425N family utilizes distinct packages for different suffixes. Confirm RoHS compliance status and moisture sensitivity level ratings prior to assembly. Ensure proper handling procedures are followed due to the component's sensitivity to static discharge and thermal management requirements during soldering.

Selection Notes

Select this component for designs requiring a 25 Watt CW output at 2450 MHz with a 28 Volt supply. Consider its integrated thermal tracking circuitry if precise bias control is needed without external complex compensation networks. Evaluate the TO-272 WB-16 plastic package constraints against the system's thermal dissipation capabilities and mounting methods.

Part Context

This part belongs to the MW7IC2425N series of lateral N-channel enhancement-mode MOSFETs from Freescale Semiconductor. The series includes variants such as the MW7IC2425NR1 and MW7IC2425GNR1, which share similar electrical characteristics but differ in packaging configurations. These devices are engineered specifically for robust performance in ISM band applications.

Replacement Considerations

Consult official documentation for direct substitutes within the MW7IC2425N family. Verify pinout compatibility and thermal resistance values when considering alternative packages like the TO-270 WB-16.
