NXH020U90MNF2PTG

$139.94

Description：MOSFET 2N-CH 900V 149A
Series：-

SKU:0f92f433db76 Category: FET, MOSFET Arrays Brand: onsemi

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：MOSFET 2N-CH 900V 149A
Series：-
Mfr：onsemi
Package：Tray
Technology：Silicon Carbide (SiC)
Configuration：2 N-Channel (Dual)
FET Feature：-
Drain to Source Voltage (Vdss)：900V
Current - Continuous Drain (Id) @ 25°C：149A (Tc)
Rds On (Max) @ Id, Vgs：14mOhm @ 100A, 15V
Vgs(th) (Max) @ Id：4.3V @ 40mA
Gate Charge (Qg) (Max) @ Vgs：546.4nC @ 15V
Input Capacitance (Ciss) (Max) @ Vds：7007pF @ 450V
Power - Max：352W (Tj)
Operating Temperature：-40°C ~ 175°C (TJ)
Mounting Type：Chassis Mount
Package / Case：Module
Supplier Device Package：-
Grade：-
Qualification：-

Download product information

NXH020U90MNF2PTG

Overview

The NXH020U90MNF2PTG is an N-channel MOSFET manufactured by onsemi, belonging to the NXH020U90MNF2PTG series. It features a maximum drain-source voltage (Vdss) of 900 V and a continuous drain current (Id) of 149 A. The device exhibits a maximum on-resistance (Rds(on)) of 14 mΩ at a gate-source voltage of 6 V. Typical gate charge (Qg) is 546.4 nC. The component supports surface mount installation via a 20-pin F2-VIENNA:外壳 180BZ package. It operates within a temperature range of -40°C to 175°C with a maximum power dissipation of 352 W.

Feature Summary

High-voltage capability with 900 V breakdown rating for robust operation in demanding power environments.
Low on-resistance design minimizing conduction losses during high-current switching applications.
Surface-mount construction utilizing a specialized 20-pin F2-VIENNA housing for efficient thermal management.

Applications

Industrial motor drives
Uninterruptible power supplies
High-frequency DC-DC converters

Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to ensure correct packaging and compliance specifications. Confirm that the F2-VIENNA package variant matches the intended PCB layout requirements. Cross-reference the RoHS status and halide-free designation with current regulatory standards before finalizing procurement orders.

Selection Notes

Select this component when designing circuits requiring a 900 V rating combined with high current handling capabilities. Evaluate the 14 mΩ on-resistance against thermal constraints to ensure junction temperatures remain within the specified -40°C to 175°C operational range. Consider the 20-pin surface-mount footprint for assembly compatibility.

Part Context

This part belongs to the NXH020U90MNF2PTG series from onsemi, designed for high-performance power switching. It utilizes advanced silicon carbide or similar high-voltage technology to achieve low loss characteristics. The F2-VIENNA packaging provides a standardized interface for industrial power modules, ensuring consistent thermal performance across production batches.
