$0.09

Description：MOSFET 2N-CH 20V 0.8A 6DFN
Series：-

SKU:62bc6eff7fb1 Category: FET, MOSFET Arrays Brand: Panjit International Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：MOSFET 2N-CH 20V 0.8A 6DFN
Series：-
Mfr：Panjit International Inc.
Package：Tape & Reel (TR)
Technology：-
Configuration：2 N-Channel (Dual)
FET Feature：-
Drain to Source Voltage (Vdss)：20V
Current - Continuous Drain (Id) @ 25°C：800mA (Ta)
Rds On (Max) @ Id, Vgs：300mOhm @ 500mA, 4.5V
Vgs(th) (Max) @ Id：1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs：1.1nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds：46pF @ 10V
Power - Max：400mW (Ta)
Operating Temperature：-55°C ~ 150°C (TJ)
Mounting Type：Surface Mount
Package / Case：6-UFDFN
Supplier Device Package：DFN1010-6L
Grade：-
Qualification：-

Download product information

PJQ1820_R1_00001

Overview

The PJQ1820_R1_00001 is a MOSFET array manufactured by Panjit International Inc. It features a 20V rating and supports an average current of 800mA at ambient temperature. The device dissipates 400mW of power under similar thermal conditions. It utilizes a surface-mount DFN1010-6L package for compact integration.

Feature Summary

Dual-channel MOSFET array configuration
Low voltage operation capability
Compact surface-mount footprint

Applications

Battery protection circuits
Power management modules
Small signal switching applications

Procurement Notes

Verify the specific datasheet version to confirm pinout compatibility with existing PCB layouts. Ensure thermal design accounts for the 400mW dissipation limit in enclosed environments. Confirm RoHS compliance status through official manufacturer documentation before finalizing component selection.

Selection Notes

Select this component when space constraints require a dual-channel solution in a DFN1010 package. Evaluate the 20V rating against peak circuit voltages to ensure adequate margin. Consider the 800mA current capacity relative to load requirements during normal operation.

Part Context

This part belongs to Panjit's MOSFET array series, designed for low-voltage switching tasks. The DFN1010-6L package provides efficient thermal performance within a minimal footprint, suitable for portable electronics and dense board designs requiring multiple switching elements.
