RS6L120BHTB1 is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Rohm Semiconductor. Its product description is NCH 60V 150A, HSOP8, POWER MOSFE. Review the specifications below when checking this part for your BOM.
Single FETs, MOSFETs specifications for RS6L120BHTB1
- Description：NCH 60V 150A, HSOP8, POWER MOSFE
- Series：-
- Mfr：Rohm Semiconductor
- Package：Tape & Reel (TR),Cut Tape (CT)
- FET Type：N-Channel
- Technology：MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss)：60 V
- Current - Continuous Drain (Id) @ 25°C：120A (Tc)
- Drive Voltage (Max Rds On, Min Rds On)：6V, 10V
- Rds On (Max) @ Id, Vgs：2.7mOhm @ 90A, 10V
- Vgs(th) (Max) @ Id：4V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs：51 nC @ 10 V
- Vgs (Max)：±20V
- Input Capacitance (Ciss) (Max) @ Vds：4080 pF @ 30 V
- FET Feature：-
- Power Dissipation (Max)：3W (Ta), 104W (Tc)
- Operating Temperature：150°C (TJ)
- Grade：-
- Qualification：-
- Mounting Type：Surface Mount
- Supplier Device Package：8-HSOP
- Package / Case：8-PowerTDFN
Single FETs, MOSFETs datasheet and documents for RS6L120BHTB1
Single FETs, MOSFETs Overview
The RS6L120BHTB1 is a single N-channel enhancement mode power MOSFET manufactured by ROHM Semiconductor. It features a 60V drain-source breakdown voltage (Vdss) and supports high continuous current capabilities, rated at 150A at ambient temperature and 120A at case temperature. The device utilizes an 8-pin HSOP surface-mount package designed for efficient thermal management. Key electrical characteristics include a low on-resistance of 3.0 mΩ at Vgs=10V, ensuring minimal conduction losses. The component operates within a junction temperature range of -55°C to +150°C and exhibits fast switching times with rise and fall times in the nanosecond range.
Single FETs, MOSFETs Feature Summary
- High current handling capability suitable for power distribution applications
- Low on-resistance for improved energy efficiency
- Robust thermal performance in compact surface-mount packaging
Single FETs, MOSFETs Applications
- DC-DC converter circuits
- Motor control systems
- Power supply output stages
Single FETs, MOSFETs Procurement Notes
Verify the specific suffix BHTB1 against official ROHM documentation to confirm pinout and thermal pad configuration. Ensure compatibility with existing PCB footprints for the 8-HSOP package. Check for RoHS compliance status in the latest datasheet revision before integration into regulated products.
Single FETs, MOSFETs Selection Notes
Select this component when high current density and low Rds(on) are required in a small form factor. Compare thermal resistance values against system heat dissipation requirements. Ensure gate drive voltage aligns with the specified threshold and full enhancement levels for optimal performance.
Single FETs, MOSFETs Part Context
This part belongs to the ROHM RS6 series of N-channel MOSFETs, which are engineered for high-current applications. The series emphasizes low on-resistance and fast switching speeds. The RS6L120BHTB1 variant specifically targets designs requiring robust performance in compact surface-mount configurations.
Single FETs, MOSFETs Replacement Considerations
Consult ROHM's official cross-reference guides for verified substitutes. Ensure any replacement matches the 60V rating, 8-HSOP package, and equivalent or superior current and thermal specifications.
Explore related parts through FETs, MOSFETs, Transistors, Discrete Semiconductor Products, all product categories.
