Product Detailed Parameters
- Description：IGBT 600V 30A 12-SIP
- Series：-
- Mfr：Sanken Electric USA Inc.
- Package：Tube
- IGBT Type：-
- Voltage - Collector Emitter Breakdown (Max)：600 V
- Current - Collector (Ic) (Max)：30 A
- Current - Collector Pulsed (Icm)：-
- Vce(on) (Max) @ Vge, Ic：-
- Power - Max：-
- Switching Energy：-
- Input Type：Standard
- Gate Charge：-
- Td (on/off) @ 25°C：-
- Test Condition：-
- Reverse Recovery Time (trr)：-
- Operating Temperature：150°C (TJ)
- Mounting Type：Through Hole
- Package / Case：12-SIP Exposed Tab
- Supplier Device Package：12-SIP
- Grade：-
- Qualification：-
Download product information
Overview
The SLA5227 is a smart power module manufactured by Sanken Electric, designed for partial switching Power Factor Correction (PFC) applications. The device integrates an IGBT and a diode bridge within a single package to reduce mounting area. It combines low-power CMOS logic with high-current, high-voltage power FET outputs to provide complete control and drive capabilities. The module features internal fixed off-time and pulse-width modulation (PWM) control of the output current. Key electrical specifications include a maximum motor supply voltage (VM) of 44V, a load supply voltage (Vs) range of 10V to 44V, and a logic supply voltage (Vcc) range of 3V to 5.5V.
Feature Summary
- Integrates IGBT and diode bridge for partial switching PFC circuits
- Combines CMOS logic with high-current power outputs
- Includes internal fixed off-time and PWM current control
- Eliminates need for complex phase-sequence programming
Applications
- Partial switching Power Factor Correction circuits
- Power supplies requiring reduced mounting area
- Applications utilizing built-in IGBT and diode bridge configurations
Procurement Notes
Verify the specific manufacturer designation, as Sanken Electric is the primary producer. Confirm the package type and pin configuration against official datasheets before integration. Ensure input voltage levels remain within the specified 3V to 5.5V logic range and 44V maximum supply limits to prevent device failure.
Selection Notes
Select this component when designing partial switching PFC topologies that benefit from integrated power and logic functions. Consider the thermal requirements associated with the PMCM package. Verify compatibility with external sensing resistors for PWM current control settings. Ensure the application does not require complex microprocessor-based sequencing.
Part Context
The SLA5227 belongs to the SLA707xM series of translator/drivers from Sanken Electric. This family combines CMOS logic with power FET outputs for stepper motor and PFC applications. The series is characterized by its ability to handle high voltages and currents while simplifying control interface requirements through built-in sequencing and protection features.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided documentation. Alternative solutions may require discrete IGBT and diode bridge components or other smart power modules from different manufacturers supporting similar partial switching PFC architectures.
