SQJA68EP-T1_BE3

$0.96

Description：N-CHANNEL 100-V (D-S) 175C MOSFE
Series：TrenchFET®
Mfr：Vishay Siliconix
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:457f8c60f5f9 Category: Single FETs, MOSFETs Brand: Vishay Siliconix

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SQJA68EP-T1_BE3 is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Vishay Siliconix. Its product description is N-CHANNEL 100-V (D-S) 175C MOSFE. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for SQJA68EP-T1_BE3

Description：N-CHANNEL 100-V (D-S) 175C MOSFE
Series：TrenchFET®
Mfr：Vishay Siliconix
Package：Tape & Reel (TR),Cut Tape (CT)
FET Type：N-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：100 V
Current - Continuous Drain (Id) @ 25°C：14A (Tc)
Drive Voltage (Max Rds On, Min Rds On)：4.5V, 10V
Rds On (Max) @ Id, Vgs：92mOhm @ 4A, 10V
Vgs(th) (Max) @ Id：2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs：8 nC @ 10 V
Vgs (Max)：±20V
Input Capacitance (Ciss) (Max) @ Vds：280 pF @ 25 V
FET Feature：-
Power Dissipation (Max)：45W (Tc)
Operating Temperature：-55°C ~ 175°C (TJ)
Grade：Automotive
Qualification：AEC-Q101
Mounting Type：Surface Mount
Supplier Device Package：PowerPAK® SO-8
Package / Case：PowerPAK® SO-8

Single FETs, MOSFETs datasheet and documents for SQJA68EP-T1_BE3

SQJA68EP-T1_BE3

Single FETs, MOSFETs Overview

The SQJA68EP-T1_BE3 is an automotive-grade N-channel MOSFET utilizing TrenchFET technology. It features a 100 V drain-source voltage and a continuous drain current of 14 A at 25 °C. The device offers a maximum on-resistance of 92 mΩ at VGS = 10 V and 117 mΩ at VGS = 4.5 V. It is housed in a single PowerPAK SO-8L package with a junction-to-case thermal resistance of 3.3 °C/W. The component supports an operating temperature range from -55 °C to +175 °C.

Single FETs, MOSFETs Feature Summary

AEC-Q101 qualified for automotive reliability standards
TrenchFET power MOSFET architecture
100% Rg and UIS tested

Single FETs, MOSFETs Applications

Automotive electronic systems
High-side or low-side switching applications
Power management circuits requiring high thermal stability

Single FETs, MOSFETs Procurement Notes

Verify the specific ordering suffix BE3 against official Vishay documentation to confirm lead-free and halogen-free compliance status. Ensure that the PowerPAK SO-8L package dimensions match your PCB footprint requirements, noting the exposed copper terminals. Confirm that the application environment stays within the specified absolute maximum ratings to maintain device integrity.

Single FETs, MOSFETs Selection Notes

Select this component when designing for automotive environments requiring AEC-Q101 qualification. Consider the 100 V rating and 14 A current capacity for appropriate load handling. Evaluate the thermal performance based on the 3.3 °C/W junction-to-case resistance and the recommended FR4 PCB mounting conditions for accurate heat dissipation calculations.

Single FETs, MOSFETs Part Context

This part belongs to the SQA series of Vishay Siliconix MOSFETs. It is manufactured using silicon technology and is designed specifically for robust performance in demanding automotive applications. The single-channel configuration allows for efficient integration into compact power stages while maintaining high efficiency through low on-state resistance.
