UPP9401/TR13

Description：RF DIODE PIN 50V 2.5W DO-216
Series：POWERMITE®

SKU:851146dbed70 Category: RF Diodes Brand: Microsemi Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF DIODE PIN 50V 2.5W DO-216
Series：POWERMITE®
Mfr：Microsemi Corporation
Package：Tape & Reel (TR)
Diode Type：PIN - Single
Voltage - Peak Reverse (Max)：50V
Current - Max：-
Capacitance @ Vr, F：1pF @ 0V, 100MHz
Resistance @ If, F：1Ohm @ 50mA, 100MHz
Power Dissipation (Max)：2.5 W
Operating Temperature：-55°C ~ 150°C (TJ)
Package / Case：DO-216AA
Supplier Device Package：DO-216
Grade：-
Qualification：-

Download product information

UPP9401/TR13

Overview

The UPP9401/TR13 is a single PIN diode from the Powermite series, manufactured by Microsemi Corporation. It is housed in a DO-216 package and features a maximum power dissipation of 2.5W. The device operates within a junction temperature range of -55°C to 150°C. Key electrical specifications include a capacitance of 1pF at 0V reverse bias and 100MHz frequency, as well as a resistance of 1 Ohm at 50mA forward current and 100MHz frequency.

Feature Summary

High isolation characteristics for signal integrity
Low insertion loss for efficient signal transmission
Low distortion performance suitable for RF applications

Applications

Two-way radio antenna switching
RF signal routing
Antenna selection circuits

Procurement Notes

Verify the specific datasheet version and manufacturer documentation to confirm pinout compatibility and thermal management requirements. Ensure that the operating conditions align with the specified junction temperature limits and power dissipation ratings before integration into final designs.

Selection Notes

Select this component when high isolation and low distortion are critical for RF switching applications. Consider the DO-216 package size and the 2.5W power handling capability relative to the system's thermal constraints and signal frequency requirements.

Part Context

This part belongs to the Powermite series of PIN diodes designed for robust RF performance. It serves as a specialized component for managing radio frequency signals in communication equipment, offering reliable switching capabilities under varying environmental conditions.

Replacement Considerations

Consult official Microsemi documentation for direct substitutes. Cross-reference with similar PIN diodes in the DO-216 package if availability is an issue, ensuring equivalent electrical parameters such as capacitance and resistance are maintained.
