UPS760E3/TR13

Single Diodes Overview

The UPS760E3/TR13 is a single-configuration silicon Schottky rectifier manufactured by Microchip Technology. It utilizes the PowerMITE3 surface-mount package and supports SMD/SMT installation. Key electrical parameters include a maximum repetitive reverse voltage (Vrrm) of 60 V and a forward current (If) rating of 7 A. The device exhibits a typical forward voltage (Vf) of 550 mV and a low reverse leakage current (Ir) of 15 uA. It withstands a forward surge current (Ifsm) of 100 A and operates within a junction temperature range of -55°C to +150°C.

Single Diodes Feature Summary

• Utilizes silicon Schottky barrier technology for high-efficiency rectification with low forward voltage drop.
• Designed in a compact PowerMITE3 surface-mount package suitable for automated assembly processes.
• Capable of handling high surge currents while maintaining low reverse leakage characteristics.

Single Diodes Applications

• DC-DC converter circuits requiring efficient power rectification
• Freewheeling diode applications in switching power supplies
• General-purpose rectification in low-voltage electronic systems

Single Diodes Procurement Notes

Verify the specific ordering suffix TR13 corresponds to the required tape-and-reel packaging configuration, as packaging variations may exist within the product family. Confirm that the PowerMITE3 footprint matches the target PCB design constraints. Ensure compliance with RoHS directives if environmental regulations apply to the final assembly. Cross-reference the manufacturer part number against official Microchip documentation to validate the exact electrical specifications before procurement.

Single Diodes Selection Notes

Select this component when a 60 V reverse voltage rating and 7 A continuous forward current are required in a small surface-mount form factor. The low forward voltage drop makes it suitable for improving efficiency in low-voltage power conversion stages. Consider the thermal management requirements associated with the PowerMITE3 package and the specified operating temperature range of up to 150°C for high-temperature environments.

Single Diodes Part Context

This component belongs to the Microchip UPS series of small-signal Schottky rectifiers. The series offers various voltage and current ratings packaged in standardized surface-mount footprints. The 'E3' suffix typically indicates lead-free and RoHS-compliant construction, while 'TR13' denotes the reel packaging format used for high-volume manufacturing integration.

Single Diodes Replacement Considerations

Consult official Microchip documentation for verified cross-reference part numbers. Substitutions must match the 60 V reverse voltage, 7 A forward current, and PowerMITE3 package dimensions. Verify that any alternative device maintains equivalent forward voltage and leakage current specifications to ensure circuit performance parity.
