VS-CPV362M4KPBF

Description：IGBT MODULE 600V 3PHASE IMS-2
Series：-

SKU:990a4e8306c8 Category: IGBT Modules Brand: Vishay General Semiconductor - Diodes Division

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IGBT MODULE 600V 3PHASE IMS-2
Series：-
Mfr：Vishay General Semiconductor - Diodes Division
Package：Bulk
IGBT Type：-
Configuration：-
Vce(on) (Max) @ Vge, Ic：-
Input：-
NTC Thermistor：No
Operating Temperature：-40°C ~ 150°C (TJ)
Mounting Type：Through Hole
Package / Case：19-SIP (13 Leads), IMS-2
Supplier Device Package：IMS-2
Voltage - Collector Emitter Breakdown (Max)：-
Current - Collector (Ic) (Max)：-
Power - Max：-
Current - Collector Cutoff (Max)：-
Input Capacitance (Cies) @ Vce：-

Download product information

VS-CPV362M4KPBF

Overview

The VS-CPV362M4KPBF is a silicon Insulated Gate Bipolar Transistor (IGBT) manufactured by Vishay Semiconductors. It features a Hex configuration and utilizes an IMS-2-13 package designed for through-hole mounting. The device supports a maximum collector-emitter voltage of 600 V and a continuous collector current of 11 A. It operates within a junction temperature range from -40 °C to +150 °C, with gate-emitter voltage limits defined between -20 V and +20 V.

Feature Summary

Hex configuration for integrated switching applications
Through-hole mounting via IMS-2-13 package
High thermal performance capability

Applications

Motor control systems
Power supply units
Inverter circuits

Procurement Notes

Verify the specific manufacturer datasheet for the VS-CPV362M4KPBF to confirm electrical characteristics and mechanical dimensions. Ensure compatibility with existing PCB footprints and thermal management requirements before integration into designs.

Selection Notes

Select this component based on the required 600 V blocking voltage and 11 A current handling capacity. Consider the IMS-2-13 package constraints for board space and heat dissipation needs in high-power density environments.

Part Context

This IGBT belongs to the CPV series from Vishay, which focuses on efficient power switching solutions. The part number indicates specific voltage and current ratings distinct from other variants in the lineup.

Replacement Considerations

Consult official substitution guides or contact Vishay support for verified equivalent parts. Do not assume pin-compatible alternatives without confirming electrical parameter alignment.
