XP50SL290DH

XP50SL290DH is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists YAGEO XSEMI. Its product description is MOSFET N CH 500V 13A TO-252(H). Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for XP50SL290DH

• Description：MOSFET N CH 500V 13A TO-252(H)
• Series：XP50SL290D
• Mfr：YAGEO XSEMI
• Package：Tape & Reel (TR)
• FET Type：N-Channel
• Technology：MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss)：500 V
• Current - Continuous Drain (Id) @ 25°C：13A (Tc)
• Drive Voltage (Max Rds On, Min Rds On)：10V
• Rds On (Max) @ Id, Vgs：290mOhm @ 4A, 10V
• Vgs(th) (Max) @ Id：5V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs：46.4 nC @ 10 V
• Vgs (Max)：±20V
• Input Capacitance (Ciss) (Max) @ Vds：1632 pF @ 100 V
• FET Feature：-
• Power Dissipation (Max)：2W (Ta), 89.2W (Tc)
• Operating Temperature：-55°C ~ 150°C (TJ)
• Grade：-
• Qualification：-
• Mounting Type：Surface Mount
• Supplier Device Package：TO-252
• Package / Case：TO-252-3, DPAK (2 Leads + Tab), SC-63
