1-776279-1

Headers, Male Pins Overview

The 1-776279-1 is an AMPMODU MOD II series connector header manufactured by TE Connectivity. It features a right-angle, panel mount design with through-hole termination for secure PCB attachment. The component provides 8 positions arranged in a single row with a 0.157-inch (4.00mm) contact spacing. Constructed from glass-filled polycarbonate, the housing ensures mechanical stability and electrical insulation.

Headers, Male Pins Feature Summary

• Right-angle configuration facilitates compact board layout integration
• Panel mount installation type provides robust structural support
• Through-hole termination ensures reliable solder joint formation

Headers, Male Pins Applications

• Industrial control system interconnections
• General-purpose electronic equipment assembly
• Signal transmission circuit boards

Headers, Male Pins Procurement Notes

Verify the specific part number against official TE Connectivity documentation to confirm current availability status. Ensure that the required pin count and pitch specifications match the target application requirements before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a right-angle, single-row header with through-hole mounting is required. The 4.00mm pitch accommodates standard wiring harnesses while the panel mount feature offers enhanced mechanical retention compared to free-hanging alternatives.

Headers, Male Pins Part Context

This component belongs to the AMPMODU MOD II series, a widely utilized line of rectangular connectors known for reliability in various industrial applications. The series offers multiple configurations including different pin counts and mounting styles to suit diverse electronic design needs.

Headers, Male Pins Replacement Considerations

Compatible substitutes within the same series include 776279-1 and 1-776279-1 variants. Verify exact pin count and orientation compatibility before substitution.
