1-794627-4

Headers, Male Pins Overview

The TE Connectivity AMP Connectors part number 1-794627-4 is a Micro MATE-N-LOK header assembly designed for surface mount applications. It features a right-angle configuration with ten positions arranged in two rows, utilizing a 3.00mm pitch. The connector employs male pin contacts made of brass with tin plating and is housed in black polyamide insulation rated UL94 V-0. Rated for 250V, it supports general-purpose board-to-cable connections via solder termination.

Headers, Male Pins Feature Summary

• Right-angle surface mount design for compact PCB integration
• Dual-row header configuration with fixed solder tails
• Four-wall shielded housing for enhanced mechanical stability

Headers, Male Pins Applications

• General-purpose electronic assemblies
• Board-to-cable interconnections
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify the specific manufacturer part number against official TE Connectivity documentation to ensure compatibility with required current ratings and thermal profiles. Confirm that the surface mount footprint matches the target PCB layout specifications before procurement.

Headers, Male Pins Selection Notes

Select this component when a right-angle, surface-mount header with a 3.00mm pitch is required. Ensure the application environment falls within the specified operating temperature range and voltage rating. Verify that the tin-plated contact finish meets the corrosion resistance requirements for the intended use case.

Headers, Male Pins Part Context

This component belongs to the Micro MATE-N-LOK series, a widely used rectangular connector system known for reliability in various industrial and commercial applications. The series offers multiple configurations including through-hole and surface mount options with varying pin counts and orientations.

Headers, Male Pins Replacement Considerations

Cross-reference with other Micro MATE-N-LOK headers sharing the same 3.00mm pitch and ten-position count. Verify identical mounting style and electrical ratings before substituting.
