1-794680-6

Headers, Male Pins Overview

The 1-794680-6 is a vertical pin header connector from the MATE-N-LOK series by TE Connectivity AMP Connectors. It features a 16-position, 2-row configuration with a 3mm (0.118 inch) centerline pitch. Designed for through-hole PCB mounting, the housing is constructed from nylon with a UL 94 V-0 flammability rating. The male contacts are made of phosphor bronze and plated with tin-lead to ensure reliable electrical connections. This component serves as a board-to-board or board-to-wire interface in electronic assemblies.

Headers, Male Pins Feature Summary

• Vertical through-hole mounting style for direct PCB integration
• Two-row layout providing 16 contact positions within a compact footprint
• Nylon insulation housing meeting UL 94 V-0 safety standards
• Phosphor bronze contacts with tin-lead plating for conductivity

Headers, Male Pins Applications

• Industrial control system interconnections
• Consumer electronics internal circuit boards
• Automotive electronic module interfaces
• General-purpose printed circuit board assembly

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official datasheet to confirm contact plating and housing color options. Ensure the selected variant matches the required current rating and voltage specifications for the target application. Cross-reference the manufacturer part number with distributor listings to confirm availability and authenticity before purchase.

Headers, Male Pins Selection Notes

Select this connector when a 3mm pitch vertical header is required for high-density signal routing. Consider the 16-position capacity and two-row arrangement for space-constrained designs. Evaluate the tin-lead plating suitability for the operating environment and mating cycle requirements compared to gold-plated alternatives.

Headers, Male Pins Part Context

This component belongs to the MATE-N-LOK family, a widely used line of rectangular connectors known for robust mechanical locking and reliable performance. The series offers various configurations for power and signal applications across automotive, industrial, and consumer markets. The 1-794680-6 specifically addresses needs for standard vertical headers with secure PCB attachment.

Headers, Male Pins Replacement Considerations

Compatible substitutes include 3-794680-6 and 794680-6, which share similar form factors and series characteristics. Verify pin count, pitch, and mounting orientation compatibility before substitution. Consult the manufacturer's cross-reference guide for exact functional equivalents.
