1-825440-6

Headers, Male Pins Overview

The TE Connectivity AMP Connectors part number 1-825440-6 is a vertical pin header connector belonging to the AMPMODU MOD II series. It features a 32-position configuration arranged in two rows with a 2.54 mm (0.100 inch) pitch. Designed for through-hole mounting, this connector supports board-to-board and wire-to-board interconnections. The contacts are made of brass with gold plating on the mating interface, while the housing is constructed from green polybutylene terephthalate (PBT).

Headers, Male Pins Feature Summary

• Vertical orientation design facilitates direct PCB insertion.
• Gold-plated contacts ensure reliable electrical conductivity.
• Two-row layout maximizes connection density within standard spacing.

Headers, Male Pins Applications

• General electronic equipment signal transmission
• Industrial control system interconnects
• Consumer electronics circuit boards

Headers, Male Pins Procurement Notes

Verify the specific contact count and row configuration against project requirements before ordering. Confirm that the through-hole mounting style aligns with the target printed circuit board layout. Ensure compatibility with mating receptacles within the same AMPMODU MOD II family to maintain mechanical integrity and electrical performance standards.

Headers, Male Pins Selection Notes

Select this component when a low-profile, high-density vertical header is required for standard 2.54 mm pitch applications. Consider the gold-plated contact finish for environments requiring corrosion resistance. Evaluate the thermal limits and current carrying capacity relative to the specific circuit load to ensure long-term reliability under operating conditions.

Headers, Male Pins Part Context

This connector is part of the extensive AMPMODU MOD II product line by TE Connectivity. The series is widely recognized for its versatility in providing robust interconnection solutions across various industries. The modular nature of the AMPMODU system allows for easy customization of position counts and configurations to meet diverse design specifications.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 32-position, 2.54 mm pitch vertical headers from the AMPMODU MOD II series, such as part numbers 1-825440-7 or 1-829394-0, provided they match the required pin count and mounting style.
