305-012-520-501

Edgeboard Connectors Overview

The EDAC Inc. 305-012-520-501 is a standard card edge connector from the 305 series, designed for dual-edge female connections. It features 12 positions with a 0.156-inch (3.96 mm) pitch. The connector utilizes gold-plated copper alloy contacts and solder termination. It is rated for 5 A current and operates within a temperature range of -40°C to +105°C. The housing is made of thermoplastic polyester, supporting board thicknesses between 0.054 and 0.070 inches.

Edgeboard Connectors Feature Summary

• Dual-edge female configuration for secure card insertion
• Gold-plated contacts ensure reliable signal transmission
• Thermoplastic polyester insulation provides thermal stability

Edgeboard Connectors Applications

• Industrial control systems requiring robust interconnects
• Telecommunications equipment interface modules
• Automotive electronics board connections

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to confirm contact plating thickness and material specifications. Ensure compatibility with the target PCB board thickness range of 0.054 to 0.070 inches before procurement. Confirm RoHS compliance status through the latest product documentation provided by EDAC Inc.

Edgeboard Connectors Selection Notes

Select this component when a dual-edge female connector with a 3.96 mm pitch is required. Ensure the application demands a 5 A current rating and operation within the -40°C to +105°C range. Verify that the mating card thickness falls within the specified mechanical limits for proper engagement and retention.

Edgeboard Connectors Part Context

This part belongs to the EDAC 305 series of standard card edge connectors. The series offers various position counts and mounting styles. The 305-012 variant specifically provides a compact 12-position solution suitable for space-constrained applications requiring high reliability and durable electrical connections.

Edgeboard Connectors Replacement Considerations

Consult the EDAC 305 Series Ordering Guide for direct substitutes with different position counts or termination types. Cross-reference compatible parts from other manufacturers only if mechanical dimensions and electrical ratings match exactly.
