450-10-224-00-106000

Headers, Male Pins Overview

The Mill-Max 450-10-224-00-106000 is a surface mount header connector featuring 24 positions with a 0.100-inch (2.54mm) pitch. Designed for high-reliability applications, it utilizes precision-machined contacts and a straight configuration suitable for board-to-board or cable-to-board interconnections. The component supports standard soldering processes and offers consistent electrical performance across its contact array.

Headers, Male Pins Feature Summary

• Surface mount termination method for automated assembly
• Precision-machined contact construction for reliability
• Straight pin configuration for standard board integration

Headers, Male Pins Applications

• Board-to-board interconnects
• Cable-to-board connections
• High-density electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to ensure the correct contact length and plating thickness match the design requirements. Confirm that the surface mount footprint aligns with the PCB layout specifications before finalizing procurement orders to prevent assembly mismatches.

Headers, Male Pins Selection Notes

Select this model when a low-profile surface mount header is required for 24-position interconnects. Ensure the application environment does not exceed the thermal limits of the standard tin plating. Verify mechanical clearance constraints around the connector height during the initial design phase.

Headers, Male Pins Part Context

This component belongs to the Mill-Max 450 series of standard pin headers. The series is characterized by high-reliability precision-machined interconnect components designed for demanding industrial and commercial electronics applications requiring robust signal transmission.

Headers, Male Pins Replacement Considerations

Cross-reference part numbers within the 450-10-2xx-00-106000 family for alternative position counts. Verify identical pitch and mounting style compatibility before substituting with other manufacturers' surface mount headers.
