5977707502F

$0.87

Description：LED GREEN/RED DIFFUSED 0404 SMD
Series：-
Mfr：Dialight
Package：Strip

SKU:3c32f166755c Category: LED Indication - Discrete Brand: Dialight

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

5977707502F is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Dialight. Its product description is LED GREEN/RED DIFFUSED 0404 SMD. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for 5977707502F

Description：LED GREEN/RED DIFFUSED 0404 SMD
Series：-
Mfr：Dialight
Package：Strip
Color：Green, Red
Configuration：Independent
Lens Color：White
Lens Transparency：Diffused
Millicandela Rating：21mcd Green, 52mcd Red
Lens Style：Rectangle with Flat Top
Lens Size：1.00mm x 0.60mm
Voltage - Forward (Vf) (Typ)：2.2V Green, 2.1V Red
Current - Test：20mA Green, 20mA Red
Viewing Angle：128°
Mounting Type：Surface Mount
Wavelength - Dominant：572nm Green, 620nm Red
Wavelength - Peak：-
Features：-
Package / Case：0404 (1010 Metric)
Supplier Device Package：404
Size / Dimension：1.00mm L x 1.00mm W
Height (Max)：0.25mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for 5977707502F

5977707502F

LED Indication - Discrete Overview

The Dialight 5977707502F is a surface-mount bi-color LED in a 0404 (1010 metric) package. It emits green light at 572 nm and red light at 620 nm with a diffused lens. The device features a rectangular lens shape, measuring 1.00 mm x 1.00 mm with a maximum height of 0.25 mm. Typical forward voltage is 2.2 V for the green element and 2.1 V for the red element at a test current of 20 mA. Light intensity is rated at 21 mcd for green and 52 mcd for red. The viewing angle is 128 degrees.

LED Indication - Discrete Feature Summary

Dual-chip configuration providing independent green and red illumination within a compact footprint
Diffused lens design ensures wide 128-degree viewing angle for enhanced visibility
Low-profile 0.25 mm height suitable for space-constrained surface-mount applications

LED Indication - Discrete Applications

Status indication on electronic circuit boards
Bi-color signaling in industrial control panels
Visual alerts in automotive instrumentation systems

LED Indication - Discrete Procurement Notes

Verify component authenticity through authorized distributors to ensure compliance with RoHS3 standards. Confirm moisture sensitivity level (MSL 3) handling requirements during storage and assembly. Cross-reference datasheet specifications against project electrical constraints before integration.

LED Indication - Discrete Selection Notes

Select this component when a low-profile bi-color indicator is required in a 0404 package. Consider the specific wavelength outputs and diffused lens characteristics for visibility needs. Ensure driving circuits accommodate the distinct forward voltages of the green and red elements.

LED Indication - Discrete Part Context

This part belongs to the Dialight 597 series of surface-mount LEDs. It utilizes standard SMD mounting techniques compatible with automated pick-and-place equipment. The 0404 form factor allows for high-density PCB layouts compared to larger PLCC packages.
