726-012-540-201

$3.48

Description：CONN EDGE DUAL FMALE 12POS 0.125
Series：726
Mfr：EDAC Inc.
Package：Bulk

SKU:236d6e4ba9af Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

726-012-540-201 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 12POS 0.125. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 726-012-540-201

Description：CONN EDGE DUAL FMALE 12POS 0.125
Series：726
Mfr：EDAC Inc.
Package：Bulk
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：6
Number of Positions：12
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.125" (3.18mm)
Read Out：Dual
Features：-
Mounting Type：Through Hole
Termination：Press-Fit, Wire Wrap
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：30.0µin (0.76µm)
Contact Type：Cantilever
Color：Black
Flange Feature：-
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 726-012-540-201

726-012-540-201

Edgeboard Connectors Overview

The EDAC Inc. 726-012-540-201 is a dual female card edge connector from the 726 series, designed for through-hole mounting. It features 12 positions with a contact spacing of 0.125 inches (3.18mm) and a row spacing of 0.250 inches (6.35mm). The connector accepts printed circuit boards with a nominal thickness of 0.062 inches (1.57mm). Constructed with copper alloy contacts featuring gold plating and a thermoplastic polyester insulator, it operates within a temperature range of -40°C to +105°C.
