A90XM6EW24FTCLP

Overview

The A90XM6EW24FTCLP is a heavy-duty disconnect enclosure manufactured by Hoffman Enclosures, Inc. It features a steel construction with a gray finish and measures 90.12 inches in height, 236.00 inches in width, and 24.12 inches in depth. The unit includes six full-size doors and utilizes a tool-free click-in mounting system for versatile configurations. Seams are continuously welded and ground smooth, while body stiffeners provide extra rigidity in larger enclosures. The design incorporates a body flange trough to exclude liquids.

Feature Summary

• Six-door configuration for comprehensive access
• Tool-free click-in mounting system for fast assembly
• Continuously welded and ground smooth seams
• Body flange trough designed to exclude liquids

Applications

• Industrial disconnect applications
• Wall-mount installations
• Floor-standing installations

Procurement Notes

Verify the exact model suffix against official nVent Hoffman documentation to confirm door count and specific dimensional tolerances. Ensure compatibility with required internal panel supports and accessories. Confirm that the steel gray finish meets environmental requirements for the intended installation site. Cross-reference the part number with current manufacturer catalogs to validate availability and standard lead times.

Selection Notes

Select this model for large-scale industrial environments requiring robust protection and multiple access points. The six-door layout suits complex electrical distributions. Consider the tool-free mounting system for rapid deployment and reconfiguration needs. Evaluate the need for additional stiffeners if the enclosure spans significant widths. Ensure the external dimensions fit the designated floor or wall space constraints.

Part Context

This component belongs to the Hoffman A90 series of heavy-duty disconnect enclosures. The series is characterized by its modular design and durable steel construction. The A90XM variant specifically denotes a multi-door configuration suitable for high-capacity disconnect applications. The product line emphasizes structural integrity and ease of assembly through patented mounting technologies.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Verify compatibility with existing infrastructure before considering alternative models from the same manufacturer family.
