AEMD-LL3K-XZ002

$0.79

Description：LED AMBER SMD 45DEG
Series：-
Mfr：Broadcom Limited
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:6cc74827749d Category: LED Indication - Discrete Brand: Broadcom Limited

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

AEMD-LL3K-XZ002 is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Broadcom Limited. Its product description is LED AMBER SMD 45DEG. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for AEMD-LL3K-XZ002

Description：LED AMBER SMD 45DEG
Series：-
Mfr：Broadcom Limited
Package：Tape & Reel (TR),Cut Tape (CT)
Color：-
Configuration：-
Lens Color：-
Lens Transparency：-
Millicandela Rating：-
Lens Style：-
Lens Size：-
Voltage - Forward (Vf) (Typ)：-
Current - Test：-
Viewing Angle：-
Mounting Type：-
Wavelength - Dominant：-
Wavelength - Peak：-
Features：-
Package / Case：-
Supplier Device Package：-
Size / Dimension：-
Height (Max)：-
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for AEMD-LL3K-XZ002

AEMD-LL3K-XZ002

LED Indication - Discrete Overview

The AEMD-LL3K-XZ002 is a single-color amber LED from the Broadcom Limited AEMD series, designed for surface-mount technology (SMD/SMT) applications. It features an oval lens shape with diffused transparency and measures 4.2 mm in length and width, with a height of 6.8 mm. The component emits light at a wavelength of 590 nm with a viewing angle of 95 degrees by 45 degrees. Key electrical parameters include a forward current of 20 mA, a forward voltage of 2.1 V, and a power rating of 120 mW. The optical intensity is rated at 2.9 cd. It operates within a temperature range of -40°C to +85°C and is supplied in reel packaging.

LED Indication - Discrete Feature Summary

Surface-mount oval lens design with diffused transparency for broad beam distribution
Amber emission color optimized for visibility in indicator applications
Standardized SMD-3 compatible footprint dimensions for automated assembly

LED Indication - Discrete Applications

Equipment status indicators
Control panel signaling
Appliance front-panel displays

LED Indication - Discrete Procurement Notes

Verify the specific ordering suffix against the manufacturer datasheet to confirm lens shape, viewing angle, and packaging type. Ensure compatibility with RoHS directives if required by the end product. Confirm moisture sensitivity handling procedures during storage and reflow soldering processes prior to installation.

LED Indication - Discrete Selection Notes

Select this component when an oval form factor with wide horizontal dispersion is required for amber signaling. Compare optical intensity requirements against alternative models in the AEMD series. Verify that the 2.1 V forward voltage aligns with the system drive circuit capabilities and thermal management constraints.

LED Indication - Discrete Part Context

This part belongs to the AEMD low-cost SMT LED family from Broadcom Limited. The series offers various colors and lens configurations including round and oval shapes. It is engineered for high-volume manufacturing environments requiring reliable surface-mount integration with standardized mechanical footprints.
