Product Detailed Parameters
- Description：LED AMBER DIFF SMT OVAL LED SMD
- Series：-
- Mfr：Broadcom Limited
- Package：Tape & Reel (TR),Cut Tape (CT)
- Color：Amber
- Configuration：Standard
- Lens Color：Amber
- Lens Transparency：Diffused
- Millicandela Rating：2140mcd
- Lens Style：Oval with Domed Top
- Lens Size：-
- Voltage - Forward (Vf) (Typ)：2.1V
- Current - Test：20mA
- Viewing Angle：100°, 40°
- Mounting Type：Surface Mount
- Wavelength - Dominant：590nm
- Wavelength - Peak：594nm
- Features：-
- Package / Case：4-SMD, Gull Wing
- Supplier Device Package：SMT Oval LED
- Size / Dimension：4.20mm L x 4.20mm W
- Height (Max)：5.70mm
- Grade：-
- Qualification：-
Download product information
Overview
The ALMD-LL36-WZ002 is a single-color amber surface-mount LED manufactured by Broadcom Limited. It features an oval lens with diffused transparency and operates at a peak wavelength of 594 nm (nominal 590 nm). The component delivers a light intensity of 2140 mcd when driven at a forward current of 20 mA, with a typical forward voltage of 2.1 V. It utilizes a 4-SMD package with gull-wing leads, measuring 4.20 mm in length and width, and up to 5.70 mm in height.
Feature Summary
- Produces amber illumination through a diffused oval lens design
- Engineered for surface-mount technology integration
- Provides standardized optical output characteristics
Applications
- Status indication on electronic circuit boards
- Visual signaling in industrial control panels
- Front panel instrumentation displays
Procurement Notes
Verify the manufacturer part number ALMD-LL36-WZ002 against official Broadcom documentation to ensure authenticity. Confirm that the specific ordering suffix matches the required amber diffused variant. Check RoHS compliance status as indicated in the product specifications. Ensure the supplier provides valid traceability records for the semiconductor components.
Selection Notes
Select this component when an oval-shaped amber indicator is required for surface-mount assembly. The 4-SMD package accommodates automated placement processes. Verify that the 2.1 V forward voltage aligns with the system drive circuitry. Ensure the mechanical footprint fits within the designated PCB area constraints.
Part Context
This device belongs to the ALMD-LL36 series of single-color LEDs from Broadcom Limited. The series offers various lens colors and configurations for general-purpose indication. The WZ002 suffix specifically denotes the amber diffused optical characteristic within this product family.
Replacement Considerations
Consult the official Broadcom datasheet for verified cross-reference information. No direct substitute part numbers are confirmed in the provided public documentation.
