AON2400 is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Alpha & Omega Semiconductor Inc.. Its product description is MOSFET N-CH 8V 8A 6DFN. Review the specifications below when checking this part for your BOM.
Single FETs, MOSFETs specifications for AON2400
- Description：MOSFET N-CH 8V 8A 6DFN
- Series：-
- Mfr：Alpha & Omega Semiconductor Inc.
- Package：Tape & Reel (TR),Cut Tape (CT)
- FET Type：N-Channel
- Technology：MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss)：8 V
- Current - Continuous Drain (Id) @ 25°C：8A (Ta)
- Drive Voltage (Max Rds On, Min Rds On)：1.2V, 2.5V
- Rds On (Max) @ Id, Vgs：11mOhm @ 8A, 2.5V
- Vgs(th) (Max) @ Id：750mV @ 250µA
- Gate Charge (Qg) (Max) @ Vgs：16 nC @ 4.5 V
- Vgs (Max)：±5V
- Input Capacitance (Ciss) (Max) @ Vds：1645 pF @ 4 V
- FET Feature：-
- Power Dissipation (Max)：2.8W (Ta)
- Operating Temperature：-55°C ~ 150°C (TJ)
- Grade：-
- Qualification：-
- Mounting Type：Surface Mount
- Supplier Device Package：6-DFN (2x2)
- Package / Case：6-UDFN Exposed Pad
Single FETs, MOSFETs datasheet and documents for AON2400
Single FETs, MOSFETs Overview
The AON2400 is an N-Channel MOSFET manufactured by Alpha & Omega Semiconductor Inc. It features a drain-source voltage (Vdss) of 8V and a continuous drain current (Id) of 15A at 25°C. The device operates with a maximum gate-source voltage (Vgs) of ±20V and has a threshold voltage (Vgs(th)) of 1.2V at 250µA. Its maximum on-resistance (Rds(on)) is 3.5mΩ at 10V gate drive and 4.5A drain current. The component utilizes an 8-SOIC surface-mount package, dissipates up to 1.9W of power, and functions within a junction temperature range of -55°C to 150°C.
Single FETs, MOSFETs Feature Summary
- Advanced trench MOSFET technology for low resistance
- Logic-level gate drive capability
- Surface-mount construction for automated assembly
Single FETs, MOSFETs Applications
- Load switch circuits
- Battery protection systems
- DC-DC converter output stages
Single FETs, MOSFETs Procurement Notes
Verify the specific datasheet revision and manufacturing origin before integration, as component specifications may vary between production batches. Confirm compliance with RoHS3 directives and REACH regulations for your target market. Ensure the selected package variant matches your PCB footprint requirements exactly. Check for any product change notices that might affect pinout or thermal characteristics.
Single FETs, MOSFETs Selection Notes
Select this component when an 8V rating suffices for the application, offering lower cost than higher-voltage alternatives. The 15A current capacity supports moderate load switching needs. Verify that the logic-level gate drive aligns with the control signal voltage levels available in the system design to ensure full enhancement.
Single FETs, MOSFETs Part Context
This part belongs to the AON240x series of low-voltage P-Channel and N-Channel MOSFETs from Alpha & Omega Semiconductor. These devices are designed for portable electronics and battery-powered applications requiring efficient power management. The series emphasizes low on-resistance and fast switching speeds within compact packages.
Single FETs, MOSFETs Replacement Considerations
Direct replacements include AO4437 and AON2403, which share similar 12V ratings and SOIC packaging. Verify that substitute parts meet the required current and thermal dissipation specifications for the specific circuit implementation.
