APTC60BBM24T3G

$84.35

Description：MOSFET 2N-CH 600V 95A SP3
Series：CoolMOS™

SKU:4589d46e8702 Category: FET, MOSFET Arrays Brand: Microchip Technology

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：MOSFET 2N-CH 600V 95A SP3
Series：CoolMOS™
Mfr：Microchip Technology
Package：Bulk
Technology：MOSFET (Metal Oxide)
Configuration：2 N-Channel (Half Bridge)
FET Feature：-
Drain to Source Voltage (Vdss)：600V
Current - Continuous Drain (Id) @ 25°C：95A
Rds On (Max) @ Id, Vgs：24mOhm @ 47.5A, 10V
Vgs(th) (Max) @ Id：3.9V @ 5mA
Gate Charge (Qg) (Max) @ Vgs：300nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds：14400pF @ 25V
Power - Max：462W
Operating Temperature：-40°C ~ 150°C (TJ)
Mounting Type：-
Package / Case：SP3
Supplier Device Package：SP3
Grade：-
Qualification：-

Download product information

APTC60BBM24T3G

Overview

The APTC60BBM24T3G is a single N-channel CoolMOS SP3F power MOSFET module manufactured by Microchip Technology. It utilizes silicon technology and features an SP3-32 package designed for screw mount installation. The device supports a drain-source breakdown voltage of 600 V and delivers a continuous drain current of 70 A. Its on-resistance is specified at 24 mΩ, with a maximum gate-source voltage range of ±30 V. The module operates within a temperature range of -40°C to +150°C and has a power dissipation rating of 462 W.

Feature Summary

Integrates a single N-channel CoolMOS SP3F power MOSFET in a compact SP3-32 module format.
Features low on-resistance for efficient power handling and thermal management.
Designed for robust screw mount installation in industrial environments.

Applications

Industrial motor drives
Uninterruptible power supplies (UPS)
High-frequency switching power converters

Procurement Notes

Verify the specific suffix T3G against official Microchip documentation to confirm RoHS compliance status and exact manufacturing lot details. Ensure the ordering part number matches the required package variant and electrical specifications precisely before finalizing procurement orders.

Selection Notes

Select this component when a 600V N-channel MOSFET with 70A continuous current capability is required. The 24 mΩ on-resistance offers a balance between conduction losses and switching performance. Consider the SP3-32 package dimensions and screw mounting requirements for PCB layout and mechanical integration.

Part Context

This module belongs to the PM-MOSFET-CoolMOS-SP3F product family from Microchip Technology. It represents a discrete power solution designed for high-efficiency applications requiring reliable thermal performance and robust electrical characteristics in a standardized module form factor.

Replacement Considerations

Consult official Microchip substitution guides for verified alternatives. Cross-reference parameters such as Vds, Id, Rds(on), and package type to ensure functional compatibility without modifying the host system design.
