Product Detailed Parameters
- Description：MOSFET 6N-CH 600V 72A SP6-P
- Series：-
- Mfr：Microchip Technology
- Package：Bulk
- Technology：MOSFET (Metal Oxide)
- Configuration：6 N-Channel (3-Phase Bridge)
- FET Feature：-
- Drain to Source Voltage (Vdss)：600V
- Current - Continuous Drain (Id) @ 25°C：72A
- Rds On (Max) @ Id, Vgs：35mOhm @ 72A, 10V
- Vgs(th) (Max) @ Id：3.9V @ 5.4mA
- Gate Charge (Qg) (Max) @ Vgs：518nC @ 10V
- Input Capacitance (Ciss) (Max) @ Vds：14000pF @ 25V
- Power - Max：416W
- Operating Temperature：-40°C ~ 150°C (TJ)
- Mounting Type：Chassis Mount
- Package / Case：SP6
- Supplier Device Package：SP6-P
- Grade：-
- Qualification：-
Download product information
Overview
The APTC60TAM35PG is a single-channel N-channel MOSFET module from Microchip Technology, utilizing CoolMOS SP3F technology. It features a 600V drain-source breakdown voltage and a continuous drain current of 72A. The on-state resistance is 35mΩ, with a gate-source voltage range of ±30V and a threshold voltage of 2.1V. Power dissipation reaches 416W in an SP-32 package. Operating temperatures span from -40°C to +150°C.
Feature Summary
- Integrates CoolMOS SP3F superjunction technology for optimized switching performance.
- Designed for screw mount installation within the SP-32 module package.
- Provides high thermal stability suitable for demanding power electronics environments.
Applications
- High-frequency power conversion systems
- Industrial motor drive inverters
- Uninterruptible power supply (UPS) units
Procurement Notes
Verify the specific suffix against official Microchip documentation to confirm exact pinout and electrical tolerances. Ensure the procurement channel provides valid RoHS compliance certificates. Cross-reference the manufacturer part number with authorized distributor lists to avoid counterfeit components. Confirm that the SP-32 package dimensions match your mechanical design requirements before finalizing orders.
Selection Notes
Select this component when a robust 600V N-channel solution is required for high-current applications. The 35mΩ on-resistance offers a balance between conduction losses and switching speed. Consider the SP-32 package constraints for thermal management and mounting hardware compatibility. Evaluate the 72A continuous current rating against peak load requirements to ensure adequate safety margins.
Part Context
This module belongs to Microchip's discrete and power modules category, specifically under MOSFET modules. It utilizes silicon technology and is part of the broader CoolMOS family designed for efficiency. The product falls under the subcategory of discrete and power modules, serving as a critical switching element in modern power electronics architectures.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided source material. Consult official Microchip documentation for potential cross-references or updated series replacements.
