APTM20SKM04G

Single FETs, MOSFETs Overview

The APTM20SKM04G is an N-channel MOSFET module from Microchip Technology, utilizing the SP6C package topology. It features a drain-to-source voltage rating of 200 V and supports a continuous drain current of 372 A at case temperature. The device exhibits a maximum on-state resistance of 5 mΩ and can handle a pulsed drain current of 1488 A. Designed for chassis mounting with FASTON connectors and screw electrical mounting, it offers high power dissipation capabilities suitable for robust industrial applications.

Single FETs, MOSFETs Feature Summary

• Integrated N-channel MOSFET technology within a compact SP6C module form factor
• High current handling capability with 372A continuous and 1488A pulsed ratings
• Low on-state resistance for efficient power conversion and reduced conduction losses
• Versatile mounting options including chassis installation and FASTON connector interfaces

Single FETs, MOSFETs Applications

• Buck chopper circuits in power electronics systems
• Industrial motor drive inverters requiring high current capacity
• Chassis-mounted power supply modules for heavy-duty equipment

Single FETs, MOSFETs Procurement Notes

Verify the specific package variant (SP6C) and electrical mounting requirements against your system design before procurement. Confirm that the 200V rating and 372A continuous current specifications align with your thermal management strategy. Ensure compatibility with FASTON connectors and screw mounting hardware. Cross-reference the datasheet for precise thermal resistance values to validate heat sink selection. Check for any recent manufacturing updates or pinout revisions.

Single FETs, MOSFETs Selection Notes

Select this component when designing systems requiring high-current N-channel switching with low on-resistance. The SP6C package is ideal for chassis-mount applications where space efficiency and robust mechanical connection are priorities. Consider the 200V voltage rating for medium-voltage DC bus applications. Evaluate thermal performance based on the 5mΩ RDS(on) and available cooling methods. This module suits applications demanding high reliability and fast switching characteristics in industrial environments.

Single FETs, MOSFETs Part Context

This part belongs to Microchip's Power MOSFET module series, specifically designed for high-power density applications. The SP6C packaging standardizes the footprint for easy integration into existing chassis designs. As an N-channel device, it complements P-channel alternatives in half-bridge configurations. The module integrates gate drive considerations within its physical layout, simplifying PCB or chassis assembly compared to discrete components.
