APTMC60TL11CT3AG

Description：MOSFET 4N-CH 1200V 28A SP3
Series：-

SKU:08d6e1a67253 Category: FET, MOSFET Arrays Brand: Microchip Technology

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：MOSFET 4N-CH 1200V 28A SP3
Series：-
Mfr：Microchip Technology
Package：Bulk
Technology：Silicon Carbide (SiC)
Configuration：4 N-Channel (Three Level Inverter)
FET Feature：-
Drain to Source Voltage (Vdss)：1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C：28A (Tc)
Rds On (Max) @ Id, Vgs：98mOhm @ 20A, 20V
Vgs(th) (Max) @ Id：2.2V @ 1mA
Gate Charge (Qg) (Max) @ Vgs：49nC @ 20V
Input Capacitance (Ciss) (Max) @ Vds：950pF @ 1000V
Power - Max：125W
Operating Temperature：-40°C ~ 150°C (TJ)
Mounting Type：Chassis Mount
Package / Case：SP3
Supplier Device Package：SP3
Grade：-
Qualification：-

Download product information

APTMC60TL11CT3AG

Overview

The APTMC60TL11CT3AG is a silicon MOSFET power module from Microchip Technology, utilizing the SP3 package. It features a four-channel configuration with a 1200V voltage rating and a continuous current capacity of 28A at Tc=85°C. The device incorporates CoolMOS technology for enhanced performance.

Feature Summary

SP3 package design for high reliability
CoolMOS technology implementation
Four-channel phase leg configuration

Applications

Industrial motor drives
Uninterruptible power supplies
High-frequency switching applications

Procurement Notes

Verify the specific suffix CT3AG to confirm reel packaging and tape specifications. Ensure compatibility with SP3 mounting requirements. Check for recent product change notifications regarding material or process updates. Confirm RoHS compliance status before integration into regulated systems.

Selection Notes

Select this component for designs requiring robust 1200V isolation in compact modules. Evaluate thermal management needs against the 28A continuous rating. Consider the SP3 footprint constraints during PCB layout. Compare switching losses against alternative technologies for efficiency optimization.

Part Context

This module belongs to Microchip's discrete and power modules category. It represents an evolution in silicon MOSFET packaging, focusing on reducing parasitic inductance. The SP3 series provides standardized mechanical dimensions for easier system integration compared to previous generations.

Replacement Considerations

Direct substitutes include other SP3 packaged 1200V four-channel MOSFETs from Microchip. Verify pinout compatibility when considering cross-manufacturer alternatives. Review datasheet electrical characteristics to ensure equivalent performance margins.
