AUIRGDC0250AKMA1

$10.16

Description：IGBT 1200V 141A SUPER-220
Series：-

SKU:5a78a2cbe98f Category: Single IGBTs Brand: Infineon Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IGBT 1200V 141A SUPER-220
Series：-
Mfr：Infineon Technologies
Package：Tube
IGBT Type：-
Voltage - Collector Emitter Breakdown (Max)：1200 V
Current - Collector (Ic) (Max)：141 A
Current - Collector Pulsed (Icm)：99 A
Vce(on) (Max) @ Vge, Ic：1.8V @ 15V, 33A
Power - Max：543 W
Switching Energy：15mJ (off)
Input Type：Standard
Gate Charge：151 nC
Td (on/off) @ 25°C：-/485ns
Test Condition：600V, 33A, 5Ohm, 15V
Reverse Recovery Time (trr)：-
Operating Temperature：-55°C ~ 150°C (TJ)
Mounting Type：Through Hole
Package / Case：TO-273AA
Supplier Device Package：SUPER-220™ (TO-273AA)
Grade：-
Qualification：-

Download product information

AUIRGDC0250AKMA1

Overview

The AUIRGDC0250 is an automotive-grade N-channel IGBT utilizing low VCE(on) planar technology. It features a maximum collector-to-emitter voltage of 1200V and continuous collector currents of 141A at 25°C case temperature and 81A at 100°C. The device exhibits a typical saturation voltage of 1.47V at 33A and 25°C, with a pulse collector current capability of 99A. Operating within a junction temperature range of -55°C to +150°C, it offers low switching losses and excellent current sharing for parallel operation.

Feature Summary

Optimized for soft switching applications with high efficiency due to low on-state voltage and switching losses
Features rugged transient performance and positive VCE(on) temperature coefficient for increased reliability
Provides excellent current sharing in parallel operation and low electromagnetic interference

Applications

PTC Heaters
Relay Replacement

Procurement Notes

Verify the specific ordering suffix against official Infineon documentation to confirm package type and standard pack quantity. Ensure compliance with automotive qualification standards required by your application. Confirm that thermal management designs account for the specified junction-to-case thermal resistance values under actual operating conditions.

Selection Notes

Select this component when designing circuits requiring robust 1200V blocking capabilities with optimized soft-switching characteristics. Consider its square RBSOA and positive temperature coefficient for reliable parallel configurations. Evaluate thermal dissipation requirements based on the specified power ratings at varying case temperatures.

Part Context

This part belongs to Infineon's automotive-qualified IGBT portfolio designed for industrial and consumer applications. It utilizes planar technology to achieve low conduction and switching losses. The Super-TO-220 package facilitates through-hole mounting suitable for various power conversion topologies.
