BC556BBK

Single Bipolar Transistors Overview

The BC556BBK is a PNP bipolar junction transistor manufactured by Diotec Semiconductor, designed for switching and audio frequency amplifier applications. It features a maximum collector current of 100 mA and a collector-emitter voltage rating of 65 V. The device operates within a temperature range of -55°C to +150°C and dissipates up to 500 mW of power. Key electrical parameters include a transition frequency of 150 MHz and a DC current gain (hFE) with a maximum value of 200.

Single Bipolar Transistors Feature Summary

• PNP polarity configuration suitable for general-purpose switching and amplification tasks
• Robust thermal performance supporting operation up to 150°C junction temperature
• High-frequency capability with a transition frequency of 150 MHz

Single Bipolar Transistors Applications

• General-purpose switching circuits
• Audio frequency amplifier stages
• Low-power signal processing applications

Single Bipolar Transistors Procurement Notes

Verify the specific suffix BBK against official Diotec documentation to confirm package type and tape/reel specifications. Ensure the requested quantity aligns with manufacturer standard packaging configurations. Confirm RoHS compliance status directly from the latest datasheet before finalizing procurement orders.

Single Bipolar Transistors Selection Notes

Select this component when a PNP transistor with 65V breakdown voltage and 100mA continuous current capacity is required. Consider the TO-92BK through-hole package for manual assembly or standard PCB mounting. Evaluate the hFE range requirements against application needs, noting the maximum gain specification provided in the datasheet.

Single Bipolar Transistors Part Context

This part belongs to the BC556 series of PNP silicon epitaxial planar transistors. The series is subdivided into groups based on current gain characteristics. The BC556 variant specifically offers higher voltage ratings compared to lower-voltage counterparts like the BC558, making it suitable for applications requiring greater collector-emitter voltage headroom.

Single Bipolar Transistors Replacement Considerations

BC557BBK: Offers similar current and power ratings but with a reduced collector-emitter voltage of 45V. Verify voltage requirements before substitution.
